XV-440-10TVB-1-50 EATON Industrial Touch Screen HMI
XV-440-10TVB-1-50 is a 10.4-inch stainless steel panel industrial touch screen human-machine interface (HMI) in the Eaton XV150 series (MICRO PANEL XV400). It belongs to the same hardware platform as the -1-10 and -1-20 in the same series, with the core difference being that the suffix “50” represents different communication interface configuration combinations.
XV-440-10TVB-1-50 EATON Industrial Touch Screen HMI
Display and control
10.4-inch TFT LCD display screen with a resolution of 800 × 600, clear image and rich colors. Supports both capacitive and resistive touch modes, supports multi touch, has built-in buttons, input boxes, images, and other rich interface elements, and supports multiple display modes such as full screen, split screen, and picture in picture.
Panel and Protection
The TVB logo represents a stainless steel front panel designed specifically for explosive environments in Zone 1 and Zone 2. It needs to be installed in a pressurized enclosure with an Ex px EC certificate and meets Class IIIC explosive environment standards. It is suitable for explosion-proof areas in industries such as chemical, pharmaceutical, food, and refining. Protection level IP65/IP67, dustproof and waterproof. The working temperature range covers -20 ℃ to+70 ℃ (some data nominal -35 ℃ to+380 ℃ short-term temperature resistance), with seismic and anti-interference capabilities.
Communication and Configuration
The core difference between the suffixes “-50”, “-10”, and “-20” lies in the communication interface configuration. This model comes standard with Ethernet (10/100/1000Mbps, supporting RJ45 electrical and SFP optical ports), serial port (RS232/RS485), USB host port, and supports multiple industrial protocols such as Modbus, EtherCAT, Profibus, etc. It can run up to four different network protocols simultaneously and has protocol conversion and data centralization functions. Compared to -1-10 and -1-20, -50 usually corresponds to higher configuration communication combinations (such as Gigabit Ethernet+multiple serial ports+CAN, etc.), which need to be confirmed by referring to Eaton’s official model comparison table.
Hardware specifications
The power supply voltage is 24V DC, the power consumption is about 120-220W, the weight is about 4.5kg, and the external dimensions are about 350 × 250 × 450mm. It has built-in security functions such as password protection and access control, and supports data recording and trend analysis.
Typical Applications
Production line monitoring in explosion-proof areas such as chemical, pharmaceutical, and food industries, as well as industrial scenarios such as power plants, steel mills, cement plants, packaging machinery, and robot control that have clear requirements for environmental adaptability and operational experience. There is also the XV-440-12TVB-1-50 (12.1-inch version) available in the same series.
In summary, XV-440-10TVB-1-50 is a 10.4-inch stainless steel panel IP65 explosion-proof industrial HMI in Eaton’s XV400 series. It features an 800 × 600 TFT screen, capacitor/resistor dual touch, stainless steel Ex px EC explosion-proof front panel, and a “-50” high-end communication interface combination (Gigabit Ethernet+multi protocol) as its core. It is a mature solution that balances operational experience, environmental reliability, and communication flexibility in hazardous areas such as chemical and pharmaceutical industries.
