Yaskawa JAMSC-B2902V | PLC Relay Output Module
Product Introduction
Relay output modules are often tied directly to field wiring—solenoids, contactor coils, pilot relays, and other discrete loads. In a legacy PLC cabinet, replacing one is not just a matter of matching the connector or module outline. Contact ratings, output grouping, terminal assignments, and controller compatibility all need to line up.
The Yaskawa JAMSC-B2902V is identified in secondary industrial-parts listings as a MEMOCON-SC PLC relay output module. The related JAMSC-B2902 is described as a 32-line relay output module with screw terminals, and JAMSC-B2902V is listed as an alternate part number. These references support the relay-output classification, but do not independently establish every suffix-specific electrical rating or wiring detail.
For maintenance teams sourcing this legacy component, the priority is to verify the complete part number against the installed module and machine drawings. Confirm the output count, load voltage, contact ratings, terminal arrangement, and controller compatibility before approving a replacement.
JAMSC-B2902V
Key Technical Specifications
- Model Number: JAMSC-B2902V
- Manufacturer: Yaskawa
- Product Family: JAMSC / MEMOCON-SC
- Module Type: PLC relay output module
- Reported Output Configuration: 32-line relay output, associated with the B2902 family
- Output Technology: Relay contact output
- Terminal Style: Screw terminals reported for the related JAMSC-B2902
- Rated Switching Voltage: Not independently verified for the exact B2902V
- Maximum Contact Current: Requires confirmation from the applicable OEM specification
- Output Grouping: Verify from the module wiring diagram
- Internal/External Power Requirements: Confirm from OEM documentation
- Controller Compatibility: Verify the MEMOCON-SC CPU/rack and system revision
- Mounting: Confirm the correct rack or base configuration
- Hardware Revision: Record from the actual unit
- Operating Temperature: Not independently confirmed for this exact model
Specification note: Do not apply ratings from newer Yaskawa I/O modules or similarly numbered JAMSC products to the JAMSC-B2902V. Confirm contact ratings, voltage limits, and terminal assignments from the applicable manual before field wiring.
Global Sourcing & Live-Test SOP
For a legacy relay output module, inspection should establish exact identity, physical condition, and the scope of functional testing.
1. Inbound Verification
- Photograph the full nameplate and all labels.
- Confirm JAMSC-B2902V, including the suffix.
- Record serial number, hardware revision, and additional OEM codes.
- Inspect the housing, terminal block, connector, and mounting features.
- Check for cracked plastic, corrosion, heat discoloration, loose terminals, or signs of repair.
- Compare terminal layout and module markings with the original installed unit.
- Retain supplier documentation and traceability records where available.
2. Electrical and Physical Inspection
- Verify the module’s electrical requirements and terminal assignments before applying power.
- Inspect screw terminals for damage, stripped threads, or oxidation.
- Check for evidence of overheating around relay and output terminals.
- Confirm the module’s relay-output classification against its label and documentation.
- Do not infer contact ratings from a related B2902 or another JAMSC output module.
- Avoid insulation testing through connected electronic circuitry.
- Record any discrepancies between the supplied unit and the customer’s original module.
3. Controlled Functional Test
A meaningful test requires the compatible Yaskawa system or a suitable test fixture.
- Confirm rack/controller compatibility before installation.
- Verify the module’s supply and wiring requirements.
- Check controller recognition and diagnostic indicators.
- Test each output channel using a controlled, appropriately rated test load.
- Verify relay switching and contact continuity under the approved test procedure.
- Check for stuck, intermittent, or non-operating outputs.
- Record the channels tested, test voltage, load conditions, and results.
A visual inspection or rack power-up alone does not establish that all relay contacts operate correctly.
4. Extended Run and Diagnostic Record
Where a compatible test setup is available, perform an extended functional run.
Monitor:
- Controller recognition and diagnostic status
- Relay switching consistency
- Contact behavior under the specified test load
- Abnormal heating
- Intermittent output operation
- Unexpected controller or module faults
Document the test duration, test equipment, output channels exercised, load conditions, and results. Do not claim a 24-hour run or full-load test unless it was actually performed and recorded.
5. Final Preparation and Shipment
- Photograph the actual unit being shipped.
- Record model number, serial number, and hardware revision.
- Protect terminals and connectors from impact and contamination.
- Use ESD-safe packaging where appropriate.
- Include available inspection and test documentation.
- Clearly state condition and warranty terms.
- Do not imply OEM certification or factory testing without supporting evidence.
Field Engineer’s Pitfall Guide
❗ Do not assume JAMSC-B2902 and are universally interchangeable
Secondary suppliers list as an alternate for JAMSC-B2902, but this alone does not establish interchangeability in every MEMOCON-SC installation. Match the exact module, terminal layout, system documentation, and application requirements before substitution.
❗ Verify relay contact ratings before reconnecting field loads
Relay output modules can be damaged by loads that exceed their contact voltage or current ratings. Confirm the exact contact specifications and output grouping before reconnecting solenoids, contactors, or other inductive loads.
❗ Do not treat a module’s physical fit as proof of system compatibility
A module that fits a rack may still be incompatible with the installed controller or wiring arrangement. Confirm the MEMOCON-SC system, slot assignment, terminal mapping, and applicable module documentation before commissioning.
Intent-Driven FAQ
What is the Yaskawa ?
It is identified in secondary industrial-parts references as a Yaskawa MEMOCON-SC PLC relay output module. The related family is described as a 32-line relay output module.
How many outputs does the have?
Secondary listings associate the family with a 32-line relay output configuration. Confirm the exact B2902V variant and output arrangement against the module label and applicable OEM documentation.
Is the a transistor output module?
Available catalog descriptions identify the family as a relay output module. Do not substitute a transistor-output module based only on a similar model number; verify the output technology and wiring requirements.
Can JAMSC- replace ?
A supplier lists JAMSC- as an alternate part number for . Treat this as a sourcing lead, not a universal compatibility guarantee. Verify the exact hardware, system revision, and field wiring before substitution.
Is the obsolete?
family appears in legacy/discontinued Yaskawa PLC parts catalogs. Confirm current OEM support and availability directly with Yaskawa or a qualified industrial parts supplier.
What should I request before buying a used ?
Request actual-unit photographs, a clear nameplate image, serial and revision details, confirmation of the relay-output configuration, condition disclosure, documented test scope, and written warranty terms.
Does a powered-up module qualify as fully tested?
No. A power-up test does not prove that every relay contact switches correctly under load. Request channel-level test results and the conditions under which the module was tested.
Bottom Line for Buyers
The is identified as a legacy MEMOCON-SC PLC relay output module, with secondary references associating the family with a 32-line relay-output configuration.
For procurement, verify the complete model number, relay contact ratings, terminal arrangement, controller compatibility, and condition of the actual unit. Request a documented output test before treating it as a production-ready replacement. If the exact electrical configuration cannot be confirmed, classify it as an unverified legacy spare, not a guaranteed drop-in replacement.
