Schneider Electric iSH070/60022/0/0/00/0/00/00/00 — Servo Motor Product Introduction

1. Product Overview

The iSH070/60022/0/0/00/0/00/00/00 is a high-performance AC synchronous servo motor manufactured by Schneider Electric under its ELAU heritage brand. It belongs to the Lexium / PacDrive motion control platform and is designed for precision motion control applications requiring high dynamic response, accurate positioning, and reliable operation in demanding industrial environments.

This motor family integrates a permanent magnet synchronous motor with an absolute multi-turn encoder directly on the motor shaft, eliminating the need for an external encoder and simplifying mechanical installation. It is widely used in packaging, printing, robotics, CNC machining, semiconductor handling, and other high-speed automation applications.

ISH0706002201000000000 Schneider servo motor

2. Model Number Breakdown

The Schneider servo motor part number follows a structured coding system. Here is how the iSH070/60022/0/0/00/0/00/00/00 decodes:

• iSH — Indicates this is an integrated servo motor from the PacDrive / Lexium family (ELAU legacy)
• 070 — Frame size designation, corresponding to a 70mm motor flange diameter
• 60022 — Stator length code and winding specification, which defines the torque class and continuous power rating of this motor
• 0 (position 4) — Cooling method; “0” means natural convection (no external fan or water cooling)
• 0 (position 5) — Shaft type; “0” typically indicates a smooth shaft with keyway (other codes include shaft with flat, hollow shaft, etc.)
• 00 (position 6–7) — Electrical connection type; specifies the motor-side connector / cable gland configuration
• 0 (position 8) — Encoder option; “0” in this position typically corresponds to a single-turn absolute encoder (e.g., EnDat 2.1 or Hiperface), while other digits may indicate multi-turn absolute or incremental encoders
• 00 (position 9–10) — Special mechanical options; “00” means standard configuration with no holding brake, no special seals, etc.
• 00 (position 11–12) — Variant / revision code; “00” indicates the standard product version

3. Key Technical Specifications (Typical for iSH070/60022)

Motor Type: Permanent Magnet Synchronous Motor (PMSM)

Frame Size: 70mm flange (compact footprint, ideal for space-constrained applications)

Stator Length / Torque Class: The “60022” code places this motor in the medium-torque range of the 070 frame family. Typical continuous torque is in the range of approximately 1.0 to 1.5 Nm (exact value depends on winding and thermal class).

Peak Torque: Approximately 3 to 4 times the continuous torque, enabling high acceleration and deceleration capabilities

Rated Speed: Typically up to 3000–4500 RPM (depending on winding), with some variants supporting higher speeds

Encoder: Integrated absolute encoder on the motor shaft, commonly EnDat 2.1 interface (single-turn or multi-turn depending on configuration). This provides high-resolution position feedback directly at the motor, eliminating backlash and improving positioning accuracy

Encoder Resolution: Typically 2048 increments per revolution (for single-turn); multi-turn variants offer 4096 × number of turns

Cooling: Natural convection (self-cooled via motor housing), suitable for ambient temperatures up to approximately 40°C without derating

Electrical Connection: Motor-side connector (M23 or similar circular connector typical for PacDrive motors), with pre-assembled cable or field-wirable options depending on the “00” connection code

Shaft: Smooth shaft with keyway (standard); shaft diameter typically around 14–19mm depending on frame

Protection Rating: IP65 or IP67 (with appropriate seal kit), suitable for dusty and washdown environments

Weight: Approximately 0.8 to 1.2 kg (very lightweight for the torque class)

Operating Temperature: -10°C to +40°C (standard); extended range options may be available

4. Compatible Drive / Amplifier

The iSH070/60022 servo motor is designed to work with Schneider Electric’s Lexium 32 series servo drives, specifically:

• LXM32AU02M3X — 200W class single-axis drive (most common pairing for this motor size)
• LXM32AU04M3X — 400W class single-axis drive (for higher dynamic performance)
• LXM32DU02M3X — Dual-axis drive module (when two motors share one drive chassis)

The drive communicates with the motor via a single power + encoder cable (smart cable technology), simplifying wiring and reducing installation time.

5. System Integration

The motor integrates into Schneider’s SoMachine Motion software environment for configuration, tuning, and commissioning. It communicates with:

• PLC / Motion Controller via EtherCAT, CANopen, or PROFIBUS (depending on the drive model)
• HMI / SCADA via Modbus TCP or Ethernet/IP for monitoring
• SoMachine Motion engineering tool for parameterization, PID tuning, and motion profile programming

Typical motion profiles supported include point-to-point positioning, velocity control, torque control, camming, and electronic gearing.

6. Key Features & Advantages

High Power Density: The 70mm frame delivers torque comparable to much larger motors from competing brands, making it ideal for compact machine designs.

Integrated Encoder: The absolute encoder is mounted directly on the motor shaft, providing true position feedback at the load point with zero backlash — critical for high-precision applications.

Wide Speed Range: From standstill to maximum rated speed with smooth torque delivery, enabling both slow precise positioning and high-speed operation.

Easy Installation: Pre-assembled motor cables, plug-and-play connector system, and auto-tuning features in SoMachine Motion reduce commissioning time significantly.

Robust & Compact: IP65/IP67 rated, lightweight (under 1.2 kg), and designed for continuous 24/7 industrial operation.

Global Support: Schneider Electric / ELAU has one of the largest servo motor installed bases worldwide, with extensive documentation, spare parts availability, and field service networks.

7. Typical Applications

• Packaging machines — high-speed pick-and-place, sealing, labeling
• Printing & converting — web tension control, register control
• CNC machining centers — axis drives for milling, turning
• Semiconductor & electronics assembly — wafer handling, bonder axes
• Robotics — joint axes in articulated robots, SCARA robots
• Textile machinery — yarn guidance, beam positioning
• Food & beverage — bottling lines, conveyor indexing (with IP67 variant)

8. Availability & Status

The iSH070/60022 series is part of Schneider Electric’s current product portfolio (not obsolete). It is actively manufactured and widely available through Schneider Electric distributors and authorized partners worldwide.

Typical lead time: 4–8 weeks for standard configurations; shorter for stock items held by local distributors.

Pricing: Varies by region and quantity; typically ranges from €500 to €1,500 per unit depending on encoder type and cable configuration.

9. Summary

The Schneider Electric iSH070/60022/0/0/00/0/00/00/00 is a compact, high-torque-density permanent magnet servo motor from the ELAU / PacDrive / Lexium family. With an integrated absolute encoder, IP65/IP67 protection, and seamless compatibility with Lexium 32 servo drives and SoMachine Motion software, it is an excellent choice for precision motion control in packaging, robotics, CNC, and other demanding automation applications. As a currently active product, it benefits from full Schneider Electric support, global availability, and a mature engineering ecosystem.

For the exact torque/speed curves, CAD drawings, wiring diagrams, or configuration files, please contact a Schneider Electric authorized distributor or visit the Schneider Electric Lexium product page on their official website.
