Description
ISH070/60017/0/0/00/00/00/00/00 is an iSH-070 series AC permanent magnet synchronous servo motor produced by ELAU (now Schneider Electric) in Germany, belonging to the PacDrive intelligent servo product line.
Interpretation of model section by section: iSH070 represents the flange size series 070; 60017 represents rated speed of 6000rpm and static torque of 1.7Nm; the first 0 represents standard coating; The second 0 represents shaftless seal; 00 represents a hybrid connector; The third 0 represents the enclosure protection level IP65; 00 represents sincos encoder; The fourth 0 represents DC 560V power supply and integrated servo electronics; The fifth 0 represents no keyway on the optical axis; 00 represents no special options.
Schneider ELAU iSH070/60017/0/0/00/0/00/00/00
Core parameters: static torque of 1.7Nm, peak torque of 7.6Nm, rated torque of 1.15Nm, rated speed of 6000rpm, 3 pole pairs, rotor moment of inertia of 0.41kg · cm ², weight of 3.4kg, protection level of IP65, encoder of sincos type, this model has not been equipped with a motor. In terms of electrical aspects, the phase to phase resistance is 4.20 Ω (20 ℃), the rated current is 1.5A, the peak current is 11.8A, and the phase to phase voltage constant is 48Vrms/1000rpm.
Product features: High dynamic response, closed-loop feedback control supports fast start stop and reverse; High precision positioning, sincos encoder provides accurate position and velocity feedback; PacDrive integrated architecture, controller, digital servo drive, intelligent motor integrated design, supporting multi protocol communication such as Modbus, Profibus, EtherCAT, etc; Strong environmental adaptability, working temperature range of -10 ℃ to+70 ℃, wide temperature version can reach -40 ℃ to+85 ℃, certified by IEC 61000 series EMC.
Typical applications cover scenarios with clear requirements for accuracy and dynamic response, such as industrial automation production lines, robot joint drives, packaging machinery, printing and textile machinery, CNC machine tools, etc.
In summary, iSH070/60017/0/0/00/0/00/00/00/00 is ELAU’s IP65 AC servo motor with a static torque of 0.72kW, 6000rpm, and 1.7Nm. It has an optical axis, sincos encoding, and no brake, making it a mature solution in PacDrive’s intelligent servo system that balances high dynamics and high precision.
