Description
The 416NHM30030A is a dual-network redundant industrial Ethernet communication module from Schneider Electric’s Modicon Quantum series, specifically designed for large-scale industrial automation control systems to enable high-speed data exchange and multi-device collaboration.
Core Functions
- Communication Connection & Protocol Conversion
- Acts as a bridge between PLCs and external devices or supervisory control systems, supporting mainstream industrial protocols such as Ethernet/IP, Modbus TCP, PROFINET, and Profibus DP for cross-system data interaction.
- Features an integrated multi-protocol conversion engine, eliminating the need for additional gateways and simplifying system integration.
- Dual-Network Redundant Architecture
- Equipped with 2 Gigabit Ethernet ports (RJ45), supporting fiber optic expansion. Automatically switches links in case of failure (response time ≤10ms) to ensure uninterrupted communication.
- Supports redundant power supply expansion for enhanced power reliability, meeting the stringent demands of industrial environments for continuous operation.
- High-Speed Data Transmission
- Ethernet ports support 10/100/1000Mbps auto-negotiation, meeting the real-time data transmission requirements of large-scale systems.
- Supports up to 64 slave devices, offering strong scalability for large industrial communication networks.
- Synchronization & Diagnostic Capabilities
- Supports IEEE 1588 PTP clock synchronization with an accuracy of ±0.1ms, meeting the time synchronization needs of distributed control systems.
- Provides communication link failure alarms, port status monitoring, and data transmission anomaly diagnostics for real-time fault localization and improved maintenance efficiency.
416NHM30030A Schneider Ethernet Communication Module
Technical Specifications
- Model: 416NHM30030A
- Brand: Schneider Electric
- Series: Modicon Quantum
- Interfaces: 2 Gigabit Ethernet ports (RJ45), supporting fiber optic expansion
- Protocols: Ethernet/IP, Modbus TCP, PROFINET, Profibus DP
- Data Transfer Rate: 10/100/1000Mbps auto-negotiation
- Supported Nodes: Up to 64 slave devices
- Operating Voltage: 24VDC ±15% (single power input), supports redundant power expansion
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% (non-condensing)
- Protection Rating: IP20 (module-level protection)
- Mounting Method: 35mm standard DIN rail mounting
- Dimensions: 160mm × 100mm × 75mm (L × W × H)
- Weight: 0.8kg
- Power Consumption: Typical 12W, maximum 18W
- Certifications: CE, UL, IEC 61131-3, UL 508, EN 61000-6-2
Applications
- Power Industry: Communication for thermal/hydro power control systems and power dispatching communication platforms.
- Petrochemical: Communication networks for refining and chemical process automation and continuous process control.
- Metallurgy: PLC communication systems for steelmaking and rolling processes.
- Smart Manufacturing: Data exchange for automated production lines and centralized control system communication for robots.
- Rail Transit: Power dispatching communication platforms.
- Pharmaceuticals: Batch process control communication.
- Water Treatment: Communication for large-scale water treatment plant control systems.
- Renewable Energy: Communication for photovoltaic and energy storage systems.
Product Advantages
- High Reliability
- Dual-network redundancy ensures automatic link switching to maintain communication continuity.
- Complies with EN 55011/EN 61000-6-2 industrial EMC standards for strong electromagnetic interference resistance.
- MTBF (Mean Time Between Failures) ≥ 2,000,000 hours for long-term stable operation.
- Compatibility & Scalability
- Seamlessly integrates with Modicon Quantum PLC systems and Schneider EcoStruxure automation platforms.
- Supports integration with third-party PLC/SCADA systems for flexible adaptation to various industrial scenarios.
- Environmental Adaptability
- Wide temperature range (0°C to 60°C) to withstand high-temperature, high-humidity, and dusty industrial environments.
- IP20 protection rating and metal shielding design for effective electromagnetic interference and dust resistance.
- Ease of Use
- Standard DIN rail mounting simplifies hardware deployment.
- Comprehensive communication diagnostic functions for real-time monitoring of port status and data transmission, reducing maintenance costs.
