Description
KEBA T70-QQU-AA0-LK is a 7-inch handheld robot teaching pendant from the KeTop T70q series of KEBA company in Austria. It is widely used for on-site programming, trajectory teaching, and production line debugging of industrial robots, and is commonly used in supporting solutions for domestic robot brands such as EFORT and Estun.
KEBA TEACH PENDANT KETOP T70-QQU-AA0-LK
In terms of core parameters, it is equipped with a 7-inch WSVGA resolution (1024 × 600 pixels) TFT color LCD screen, using an analog resistive touch screen, supporting finger or stylus operation, and can still accurately touch in industrial environments such as oil stains, humidity, and wearing gloves. 17 film buttons are integrated on the front, equipped with a 3-stage safety enable switch (2 channels) and an emergency stop button (2 channels), and a key switch is optional. The size is about 250 × 210 × 50 mm, the weight is about 960g (excluding cables), the shell is made of ABS-PC material, the color is RAL 7016 coal gray, and the protection level is IP65. The dual core version has a working temperature range of 0 ° C to 40 ° C, a storage temperature range of -25 ° C to 70 ° C, a power supply of 24V DC, and a maximum current of about 400mA. It is equipped with a built-in Cortex A9 processor, 4GB Flash storage, and at least 1GB RAM. The communication interface is Ethernet 10/100 Mbit/s, and data can be backed up through USB 2.0.
Functionally, it supports robot trajectory drag and drop teaching, coordinate system switching, program editing and downloading, and can be adapted to various scenarios such as six axis robotic arms, collaborative robots, injection molding machines, welding equipment, etc. Modular design allows for subsequent upgrades to processing performance without the need to modify the overall solution. The ergonomic grip structure is suitable for long-term operation, and the anti slip pattern on the back cover is suitable for use with protective gloves.
Typical applications cover industrial sites with high requirements for mobile operation and visualization, such as automotive welding production lines (six axis robotic arm trajectory teaching), collaborative robot debugging in food and beverage factories, remote operation of injection molding and die-casting machines, and feed control of CNC machine tools.
Summary in one sentence: T70-QQU-AA0-LK is a 7-inch handheld terminal for robot teaching in the KEBA T70q series. With IP65 protection, resistive touch screen, three-stage enable switch, and modular architecture as its core, it is a mature solution for industrial field mobile control and robot programming.
