B&R 5PC910-SX02-00 | APC910 Industrial Computer Box Controller
Product Introduction
The 5PC910.SX02-00 is a core base housing and system engine within B&R’s flagship Automation PC 910 (APC910) industrial computer family. Denoted by the .SX02 designation, this specific chassis configuration features a 2-slot expansion housing, offering a compact footprint while still providing two dedicated PCI/PCIe slots for fieldbus option cards (such as POWERLINK, PROFINET, or CAN bus) or frame grabbers.
Engineered to operate continuously in demanding industrial environments, the 5PC910.SX02-00 uses an industrial steel enclosure designed for high resistance to electromagnetic interference (EMI), shock, and vibration. Powered by 3rd Generation Intel Core processors, it easily manages deterministic Automation Runtime control loops alongside Windows-based HMI applications using hypervisor technology. Installing a bench-tested, genuine replacement unit clears system bottlenecks and prevents machine downtime caused by hardware failure on aging production lines.
5PC910.SX01-00
Key Technical Specifications
| Parameter | Technical Specification |
| Manufacturer | B&R Industrial Automation |
| Part Code | 5PC910.SX02-00 / 5PC910-SX02-00 |
| Product Family | Automation PC 910 (APC910) |
| Chassis / Slot Type | 2-Slot Expansion Housing (PCI / PCIe backplane options) |
| Chipset | Intel Mobile QM77 Express Chipset |
| Memory Slots | 2x DDR3 / DDR3L SO-DIMM sockets (Up to 16 GB supported) |
| Retain Memory | 512 kB battery-backed SRAM for non-volatile data preservation |
| Network Interfaces | 2x 10/100/1000 Mbit/s RJ45 Gigabit Ethernet (Intel controllers) |
| Video Outputs | 1x DVI-I, 1x DisplayPort (Supports optional SDL/SDL3 transmitter cards) |
| I/O Ports | 4x USB 3.0, 1x RS232 (9-pin DSUB), 1x CFast slot, 1x Slide-in drive bay |
| Supply Voltage | 24 VDC Nominal (±25% SELV isolated terminal input) |
| Operating Temperature | 0°C to +55°C (32°F to 131°F, configuration dependent) |
Application Scenarios & Pain Points
Field Experience: A high-speed bottling plant experienced random fieldbus drops whenever an aging 2-slot IPC reached thermal capacity during summer production peaks. The internal power supply rail was fluctuating under heavy CPU load. Swapping in a bench-tested 5PC910.SX02-00 unit restored stable 24V regulation and eliminated network dropout faults across all three shift runs.
- With Genuine 10.: High multi-core computing throughput, compact 2-slot cabinet integration, zero packet loss over dual Gigabit LAN ports, and stable hypervisor execution.
- Without (Uncertified Third-Party IPC): Unpredictable latency spikes under Automation Runtime, premature fan and capacitor degradation, and video signal loss across Smart Display Link runs.
- Mid-Sized Control Enclosures: Provides high-end computing power in tight control cabinets where a full 5-slot chassis cannot fit.
- Integrated Motion & Vision Stations: Executes multi-axis servo trajectories while processing image feeds through a PCI/PCIe frame grabber card inserted into one of the two expansion slots.
QA & Live Testing SOP (Trust Signal)
Every 10. unit pulled from inventory undergoes a multi-step bench qualification process prior to shipping:
- Physical & Backplane Inspection: We inspect the galvanized chassis, 2-slot card guides, front access cover, and power input plug for mechanical wear, bent pins, or thermal stress.
- 24V Rail & SRAM Battery Check: The internal 24V DC-to-DC converter is tested under full electrical load, and the 3V lithium coin cell is verified for stable SRAM retain variable storage.
- Multi-Port Data Loopback: Dual Gigabit Ethernet ports, all four USB 3.0 sockets, RS232, and DVI/DisplayPort outputs are tested simultaneously under high-data loops.
- Thermal Stress Sweep: The unit undergoes multi-hour diagnostic burn-in inside a heated test chamber to verify heat dissipation across the heatsink and fan assemblies.
- Anti-Static ESD Packaging: Verified units are cleaned, sealed in ESD protective shielding, and packed into custom foam-lined shipping boxes.
Field Engineer’s Pitfall Guide
- ❗ Difference Between .SX01 and . Housing: The
.SX01prefix generally denotes a 1-slot or single-slot housing variant, whereas.denotes a 2-slot expansion housing. Ensure your control cabinet depth and backplane slot requirements match the.form factor before mounting. - ❗ Memory Type Verification (DDR3 vs. DDR3L): The QM77 chipset requires industrial-grade DDR3 or DDR3L SO-DIMM RAM. Standard non-ECC consumer RAM sticks can cause random memory parity errors or boot failure under Automation Runtime.
- ❗ Secure CFast Boot Media Properly: When transferring your CFast boot card from your old IPC to the 10., push the card firmly into the slot until the mechanical locking latch seats completely. A loose card will result in “No Operating System Found” boot errors.
Intent-Driven FAQ
Q: What does the “.” suffix mean in the 10. part number?
A: The “.” designation identifies the 2-slot expansion housing variant of the Automation PC 910 system unit, allowing up to two PCI or PCIe add-on cards to be installed.
Q: Can I run B&R Automation Runtime and Windows 10/7 simultaneously on this unit?
A: Yes. The 10. fully supports B&R hypervisor technology, allowing real-time PLC logic (Automation Runtime) to run concurrently with a Windows operating system without real-time performance trade-offs.
Q: How do I connect remote Automation Panels to the 10.?
A: The unit features native DVI-I and DisplayPort interfaces, and can accept modular B&R Smart Display Link (SDL or SDL3) transmitter cards to stream video and touch data up to 100 meters over a single cable.
Q: What power input is required to operate the unit?
A: It requires a nominal 24 VDC (±25%) power feed connected via a standard B&R 3-pin cage-clamp terminal plug.
Q: What condition are these units supplied in, and what warranty is included?
A: We provide fully bench-tested New Surplus and reconditioned original B&R units. Every 10. unit includes a 1-year functional replacement warranty and full QA bench clearance.
