Description
V17152310 ABB temperature transmitter
ABB V17152310 (also known as V17152-310) is an intelligent temperature transmitter in ABB’s measurement and analysis product line,
and is also classified as a summation and counting module in the Contrans I series in some industrial control systems. The following introduces temperature transmitters as the main positioning.
In terms of core parameters, the input voltage range is 12-48V DC, and the output is a 4-20mA linear signal with deep integration of the HART protocol. It supports remote parameter configuration and equipment diagnosis by superimposing FSK digital signals on analog signals. The measurement accuracy is 0.08% digital accuracy, with an overall accuracy of 0.1K (Pt100), and a long-term stability of 0.05% per year. The input type is compatible with thermal resistors (2-4 wires Pt100, etc.), thermocouples, and resistance signals (-125 to 1100mV). The protection level is IP66, and it has passed ATEX Exia Zone0, FM, CSA explosion-proof certification. It also has SIL2/SIL3 functional safety certification (IEC 61508/IEC 61511) and has obtained certifications from metrology and classification societies such as OIML R71, PTB Type Approval, DNV-GL, etc.
In terms of physical specifications, it measures 170mm x 105mm x 32mm, weighs approximately 120g, operates within a temperature range of -20 ° C to+50 ° C, has an energy conversion efficiency of over 90%, and adopts a compact design for easy on-site integration and installation.
Functionally, it supports dual channel communication via HART, enabling remote calibration, fault diagnosis, and parameter adjustment. Equipped with a high-performance processor, it is suitable for scenarios that require high-precision temperature monitoring and remote management.
Typical applications cover industries such as petrochemicals (temperature monitoring of oil wells, storage tanks, and pipelines), electricity (temperature monitoring of power plants and substation equipment), metallurgy (temperature control of smelting furnaces and rolling mills), food and beverage (temperature control during production to ensure product quality and safety), and water treatment.
In summary, V17152310 is a high-precision intelligent temperature transmitter from ABB, with 4-20mA+HART output, IP66 protection, SIL2/SIL3 safety certification, and wide input compatibility as its core. It is suitable for industrial sites with high requirements for temperature measurement accuracy and remote management.
