Description
ABB PP865 3BSE042236R1 Panel 800 Operator Panel HMI Touch Screen Operator Panel
[Product Positioning]
PP865 3BSE042236R1 is a 10.4-inch color touch screen operator panel in the ABB Panel 800 series, belonging to the human-machine interface (HMI) terminal device of the ABB 800xA automation system. It is an upgraded version (StepUp, suffix A) of PP845 (3BSE042235R1), used for real-time interaction between operators and control systems such as AC800M and SD series (SPC800), realizing process monitoring, parameter setting, alarm management, and control operations.
PP865 3BSE042236R1 Touch Panel
Display and Interaction
The screen size is 10.4-inch TFT-LCD color LCD display, with a resolution of 800 × 600 pixels (SVGA), supporting 64K color display, and can present clear graphics, animations, trend charts, and text information. Adopting resistive touch screen technology (4-wire simulation), it supports finger and glove operation, and can be clearly recognized under various lighting conditions. High brightness LED edge backlight array with a backlight lifespan of 50000 hours. Support multi language switching and adapt to the needs of operators in different regions.
Processor and Performance
Equipped with ARM Cortex-A8 processor, with a clock speed of 800MHz, running Windows CE embedded operating system. The memory configuration is 256MB RAM+256MB Flash, with 2GB of onboard storage space for storing application images and cyclic trend data. The system startup time is less than 8 seconds, and it can quickly enter the flowchart screen after power on. Supports up to 50 four line alarm messages, with a maximum of 32 characters per line.
[Communication Interface]
Equipped with 2 10/100Mbps Ethernet RJ45 ports (supporting redundant network configuration and daisy chain connection to multiple panels), 1 isolated RS-485 serial port (supporting protocols such as Modbus RTU), and 1 USB-A service port (for data backup, firmware upgrade, and maintenance). Supports mainstream industrial communication protocols such as Modbus TCP/RTU, Profibus DP, OPC, EtherNet/IP, and can seamlessly integrate with AC800M series controllers (PM860, PM891, PM902F, etc.), SD series controllers (SPC800 series), and third-party SCADA systems. The front panel is equipped with a mini USB diagnostic port for local debugging and diagnosis.
[Physical Specifications]
Front panel dimensions: width 275 mm x height 215 mm x depth 52 mm, installation opening size approximately 259 x 201 mm, panel installation thickness 2-12 mm. Net weight approximately 2.0 kg. Front panel protection level IP65 (NEMA 4X when installed), effectively dustproof and waterproof, suitable for flushing environment. Rear protection level IP20. Adopting DIN rail installation method. The working temperature range is -20 ° C to+60 ° C, and the storage temperature is -40 ° C to+85 ° C.
Power Supply and Certification
The working power supply is 24V DC (18-30V DC), with a typical power consumption of about 15W. The auxiliary power supply range is AC/DC 85-270V. Passed certifications such as CE, cULus, UL 508, RCM, RoHS, etc. HS code 84714100. Compliant with IEC 61000 series electromagnetic compatibility standards and ISA S71.04 G1/G3 environmental grade requirements.
[Functional Features]
Support functions such as alarm management, real-time trend charts, recipe management, and user permission grading. Up to 50 four line alarm messages can be provided, with a maximum of 32 characters per line. Supports 10 menu languages and related character sets. Built in visualization function, capable of displaying Ticker text, bar charts, I/O status switching, and more. Equipped with 6 standard function keys and 4 additional function input buttons, supporting direct input into program code. Screen configuration and program download can be performed through ABB 800xA system software (Panel Builder 800, formerly known as 800xA Panel Builder). Built in web server, supports remote monitoring. Equipped with an SD card slot for easy application backup and recovery.
Typical application areas
Widely used in industrial automation scenarios that require local human-machine interaction, such as oil and gas, thermal power generation and new energy, chemical process control, water/wastewater treatment, pulp and paper, cement and building materials, metallurgy, district heating, food and beverage, pharmaceuticals, etc. It is usually used in conjunction with AC800M series controllers (PM860, PM891, PM902F, etc.) and SD series controllers (SPC800 series), especially suitable for on-site operation positions with ample space but high reliability requirements.
