O4LE 1KHL01555R0001 ABB control card
ABB O4LE 1KHL01555R0001 Control Card (I/O Module) Product Introduction
O4LE 1KHL01555R0001 ABB control card
Product Overview
| project | content |
|---|---|
| Product Model | O4LE |
| Product Number | 1KHL01555R0001 |
| Manufacturer | ABB (Switzerland) |
| Product Type | Digital Output Module (DO Module) / Control Card |
| Belonging System | ABB AC 800M / LM80 / 800xA DCS Distributed Control System |
| Core Functions | The controller’s digital signals are converted into switch outputs to drive field loads such as relays, solenoid valves, and indicator lights. |
🔧 Core Technical Parameters
| Parameters | Specification |
|---|---|
| Number of channels | 16-channel digital output |
| Output type | Relay output |
| Rated voltage | 24V DC |
| Rated current | 2A / Channel |
| Load power | 30W / Channel |
| Contact form | SPDT (Single-hand double throw, 1 normally open + 1 normally closed) |
| Response time | < 1ms |
| Insulation voltage | 2500Vrms (Inter-channel electrical isolation) |
| Operating temperature | -20°C ~ +70°C |
| Storage temperature | -40°C ~ +85°C |
| Humidity range | 5% ~ 95% (non-condensing) |
| Installation method | DIN rail/panel mounting, hot-swappable |
| Module size | Approximately 22.5mm × 99mm × 110mm (length × width × height) |
| Communication interface | Communicates with the CPU via the baseboard bus (AC 800M bus) |
