ABB S-073N 3BHB009884R5211 High voltage frequency converter power unit
3BHB009884R5211 S-073N
Product Name: ABB S-073N High Voltage Inverter Phase Module
Brand: ABB
Series: ACS6000 Medium Voltage AC Drive System
Product type: High voltage frequency converter power unit/phase module (inverter module)
ABB S-073N 3BHB009884R5211 High voltage frequency converter power unit
Core function: As the core power conversion unit of the ACS6000 series high-voltage frequency converter, it is responsible for converting the DC bus voltage into controllable three-phase AC output to drive the operation of the high-voltage motor. Adopting IGCT (Integrated Gate Converter Thyristor) technology to achieve efficient power conversion under high voltage and high current conditions. Simultaneously equipped with overcurrent protection, over temperature protection, and short-circuit protection, real-time monitoring of the phase module is carried out to prevent damage.
Technical features:
IGCT three-level circuit design, combining the advantages of thyristors and transistors, with high withstand voltage, high current processing capability, and low conduction loss
Fast and accurate current on/off control, fast switching speed, high energy efficiency
High reliability and surge resistance, suitable for harsh industrial environments
Electrical and ground wire isolation design to reduce interference
Dual optical ports achieve dual fiber ring network redundancy, improving system reliability
Communication and Interface:
Support DCS Link for fast point-to-point communication, with direct data exchange between drivers
Supports industrial communication protocols such as Profibus DP and Modbus
Fiber optic communication interface, supporting long-distance high-speed transmission
Input/output specifications:
DC input voltage range: DC 200-750V (typical application)
Output: Three phase AC, driving high-voltage motor
Supports three modes: position control, speed control, and torque control
Pulse input frequency: up to 5MHz
Encoder input: used for precise position feedback
Physical parameters:
Installation method: 35mm DIN rail installation
Protection level: IP30
Power supply: DC 9-36V wide voltage input, supporting dual power redundancy
Working temperature: -25 ° C to+70 ° C (some versions may cover a wider range)
Weight: Approximately 1-2kg (depending on specific configuration)
Application fields:
Power industry: High voltage motor drives for boiler fans, induced draft fans, water pumps, etc. in power plants, voltage regulation and reactive power compensation in substations
Oil and gas: drilling platform compressors, pumps, and fan drives, natural gas pipeline motor control
Metallurgy and mining: High pressure rolling mill drive, mining crusher, conveyor belt, winch
Chemical and pharmaceutical industries: large-scale mixers, centrifuges, fans, and compressors with variable frequency control
Cement building materials: kiln blower, cooling fan, crusher drive
Paper and textile: driven by blowers, presses, and mixers
Rail Transit: Subway, Light Rail Electric Drive System
New energy: wind power generation, photovoltaic grid connected power conversion
Related models in the same series:
S-073N 3BHB009884R0021: Basic version phase controller module, rated power 750W, current 0-3A
S-053M 3BHB012897R0003: Modules of the same series but with different specifications
S-093H 3BHB009885R0004: Higher power level phase module
LDMTR-01 (3BHB007445P0001): ACS6000 matching I/O module
BCU-02 (3AUA0000110429): BCU series control unit, can be used in conjunction with S-073N
KUC755AE105 (3BHB005243R0105): Drive power board, providing power to S-073N
Product positioning: S-073N ALU 3BHB009884R5211 belongs to the ACS6000 series of dedicated phase modules for medium and high voltage high-power drives. Compared with ordinary frequency converter power units, it has higher voltage levels and stronger impact resistance, suitable for heavy industry scenarios with extremely high requirements for drive reliability and energy efficiency.
Product status: Active in production, available from the original factory and authorized channels. There are multiple suppliers in Xiamen offering this model in stock.
