Description
ABB PPC380AE01 HIEE300885R1 Panel 800 Compact Control Module
[Product Positioning]
PPC380AE01 HIEE300885R1 is a compact control module in the ABB Panel 800 series, belonging to the core functional unit of the ABB 800xA automation system. This module integrates power management and output control functions, targeting industrial automation field application scenarios that require high reliability relay output or power distribution. It is an important supporting module for AC800M series controllers (PM860, PM891, PM902F, etc.) and SD series controllers (SPC800).
ABB HIEE300885R1 PPC380AE01 Module
[Core Function]
This module mainly undertakes the dual tasks of relay output control and power management. Built in high-quality relays and stable circuit design, supporting multiple output configurations (single contact, double contact, normally open, normally closed, etc.), can directly drive on-site actuators such as solenoid valves, contactors, alarm lights, etc. At the same time, it has the ability to adjust power output, supporting users to configure power parameters of different voltage and current levels according to their needs, to meet the power supply needs of different devices. Equipped with multiple protection mechanisms such as overcurrent protection, overvoltage protection, and short circuit protection, ensuring stable operation of the equipment in harsh environments such as high load and high temperature.
Communication and Interface
Supports mainstream industrial communication protocols such as Modbus RTU/TCP, Profibus DP, OPC, etc., and can seamlessly integrate with AC800M series controllers, SD series controllers, and third-party PLCs. Provide RS-232/RS-485 serial port and Ethernet interface for convenient data exchange and remote monitoring with other devices. The front panel is equipped with LED status indicator lights, which can quickly determine the module’s operating status and fault area.
Processor and Performance
Adopting an embedded processor architecture, supporting real-time control task scheduling. Short cycle time, capable of meeting millisecond level control response requirements. Built in web server, supporting remote monitoring and parameter configuration. Support functions such as alarm management, trend recording, and user permission grading.
[Physical Specifications]
Adopting a compact shell free or thin shell design, the installation method is 35mm DIN rail. The working temperature range is -25 ° C to+60 ° C, and the storage temperature is -40 ° C to+85 ° C. The protection level is IP20 (front panel), suitable for installation in industrial control cabinets. Low power consumption, no need for fan cooling, truly achieving maintenance free operation.
Power Supply and Certification
The working power supply is 24V DC (18-32V DC). Passed certifications such as CE, cULus, UL 508, etc. Compliant with IEC 61000 series electromagnetic compatibility standards and ISA S71.04 G1/G3 environmental grade requirements. HS code 84714100.
Programming and Configuration
Use ABB 800xA system software (Control Builder M/Compact Control Builder/Panel Builder 800) for screen configuration and program download, seamlessly integrate with ABB 800xA system, and support unified project management. Support offline simulation, which can verify the correctness of the application program before powering on.
[Typical Application]
Widely used in industrial automation scenarios such as oil and gas, thermal power generation and new energy, chemical process control, water/wastewater treatment, pulp and paper, cement and building materials, metallurgy, mining, etc. Typical applications include: driving and interlocking control of solenoid valve groups, power distribution and protection of on-site equipment, alarm output driving, and relay logic replacement in old station renovation. Usually used in conjunction with AC800M series controllers and SD series controllers, it is particularly suitable for on-site control cabinets with limited space but high reliability output control requirements.
