ABB CP435T 1SBP260193R1001 Touch Screen Panel

Brand: ABB

Product Series: CP400 Series HMI Panels / Control Terminal Family

Model: CP435T (Part Number: 1SBP260193R1001)

Product Type: Graphical Touch Screen HMI Panel / Control Operator Interface

ABB CP435T 1SBP260193R1001 Touch Screen Panel

Technical Parameters:

Display Size & Resolution: 10.4-inch TFT color LCD display offering VGA resolution (640 x 480 pixels) with 65,536 colors for clear graphical process visualization.

Touch Screen Technology: High-precision analog resistive touch screen supporting continuous multi-touch and gloved finger operation in harsh shop-floor environments.

Processor & System Memory: Built on a high-speed 32-bit RISC processor with 4 MB Flash memory for application storage and 16 MB dynamic system RAM.

Communication Interfaces: Integrated multi-port communication suite featuring 1x Ethernet 10/100 Mbit/s (RJ45), 1x RS-232, 1x RS-422/RS-485 serial interface, and 1x USB host port for software downloads and data logging.

Supported PLC Protocols: Pre-loaded with drivers for multi-vendor PLC platforms including ABB AC500, Modbus RTU/TCP, Siemens S7, Allen-Bradley DF1/EtherNet/IP, and Omron protocols.

Operating Power Supply: Standard 24 V DC auxiliary input voltage range (18 V DC to 30 V DC) with low power consumption (approx. 10 to 15 W).

Enclosure & Protection Rating: Rugged NEMA 4X / IP65 rated front panel enclosure resistant to water spray, dust ingress, and industrial chemical splash.

Operating Thermal Range: Rated for extended industrial operating temperatures from 0°C to +50°C and storage temperatures down to -20°C.

Industrial Sectors:

Factory Automation & OEM Machinery, Food and Beverage Processing, Water and Wastewater Infrastructure, Building Automation & HVAC, Packaging & Material Handling, and Plastics Processing.

Application Scenarios:

1. Operator Machine Control & Monitoring: Mounted directly on control panel doors of automated packaging and bottling lines to display real-time machine status, motor speeds, and cycle times.

2. Recipe Management & Parameter Adjustment: Used in chemical batching and food processing plants to store, select, and adjust production recipes and dosing parameters directly from the touch interface.

3. Alarm Logging & System Diagnostics: Integrated into municipal water pumping station cabinets to record real-time fault alarms, plot pressure trend curves, and display system maintenance alerts.

4. Multi-Vendor Automation Integration: Positioned in standalone manufacturing cells to bridge communications between different PLC brands and deliver a unified operator interface on a single screen panel.
