OLDI 56SAM-810 | Industrial PLC Communication & Interface Card
Dynamic Product Introduction
System integration bottlenecks on legacy PLC platforms usually stem from protocol incompatibilities rather than processor memory limits. When an aging automation cell requires data exchange with specialized third-party instrumentation, forcing standard I/O cards to handle the translation causes massive logic scan delays. Deploying the Online Development Inc. 56SAM-810 resolves this communication friction directly, integrating custom field devices into the host backplane without requiring a complete control architecture overhaul.
In field refits, utilizing this specialized module stabilizes data polling rates while preserving existing ladder logic structures. (Though verifying processor slot current capacity prior to insertion remains essential.) It handles complex telegram structures cleanly, maintaining deterministic communication loops across demanding industrial environments.
56SAM-810
Key Technical Specifications
| Technical Parameter | Specification Detail |
| Device Category | Special Application Communication Module |
| Series Compatibility | Allen-Bradley SLC 500 / OLDI SAM Architecture |
| Backplane Interface | Standard SLC rack slot connection |
| Power Consumption | Low-draw backplane current profile |
| Operating Temperature | 0^\circC to 60^\circC |
| Storage Temperature | -40^\circC to 85^\circC |
| Diagnostic Indicators | Multi-status LED array (OK, Comm, Error, TX/RX) |
| Enclosure Coating | Industrial conformal protective barrier |
