Bachmann AIO2881 | 8-Channel Analog Input & Output PLC Card
Dynamic Project Introduction
Industrial automation and renewable energy systems—such as wind turbine controllers and complex manufacturing skids—require high-speed, dense analog signal processing to monitor and regulate variables smoothly. The Bachmann Electronic AIO288/1 (widely referenced as AIO2881) handles this multi-parameter requirement within the modular M1 controller ecosystem, offering 8 flexible analog inputs and 8 analog outputs on a compact footprint.
When replacing legacy or failing automation hardware within an active Bachmann M1 rack, maintaining exact model and suffix nomenclature ensures seamless backplane communication, precise signal scaling, and proper terminal block integration without control software alterations.
AIO2881
Key Technical Specifications
| Parameter | Specification Detail |
| Primary Architecture | Bachmann M1 System Analog Input/Output Module |
| System Compatibility | Bachmann M1 Controller Racks & Distributed I/O Nodes |
| Analog Inputs | 8 channels (\pm 10V, \pm 1V, 20mA, and 4x Pt100/1000 configurations) |
| Analog Outputs | 8 channels (\pm 10V) plus integrated potentiometer supply options |
| Conversion Resolution | 14-bit analog-to-digital and digital-to-analog processing |
| Sample Time | 200 \mus fast acquisition cycle |
| Isolation Profile | Non-isolated variant (/1 suffix build designation) |
| Form Factor & Mounting | Compact DIN-rail mountable module with plug-in spring clamp terminal blocks |
