Description
S22460-SRS Kollmorgen s200 series driver
Kollmorgen S22460-SRS is a high-performance fully digital servo drive in the Kollmorgen (Danaher brand) S200 series, designed for precise control of servo motors and widely used in industrial automation and motion control fields.
S22460-SRS Kollmorgen s200 series driver
In terms of core parameters, the operating voltage supports two modes: 120/240VAC and 20 to 90VDC. The rated current range is from 1.5 amperes RMS continuously to 48 amperes RMS peak. The speed loop bandwidth can reach up to 800 Hz, and the current loop bandwidth is 3 to 5 kHz, with fast response speed and smooth motion. The feedback system adopts a 24 bit high-resolution ∑ – Δ ADC, integrating a programmable gain array and a reference voltage source to ensure the accuracy of position control. The driver is equipped with an intelligent feedback device and an electronic motor nameplate, which can achieve plug and play debugging in most applications, greatly reducing on-site configuration time.
In terms of communication and control, the S22460-SRS comes pre installed with the SynqNet tab and connects to the SynqNet real-time synchronization network through a standard RJ45 interface. This network is based on synchronous Ethernet technology and is designed specifically for multi axis high-precision motion control, supporting nanosecond level clock synchronization. The driver also supports up to 18 bit analog reference input and encoder equivalent output, providing standard functions such as torque control and speed control base, electronic transmission device, etc. The programmable motion control options support indexing control or multi axis coordinated control based on SynqNet.
In terms of protection functions, it has multiple protections such as overcurrent, overvoltage, and overheating to ensure the safe operation of the equipment under abnormal working conditions. Modular design makes maintenance and component replacement easier, with shorter maintenance cycles.
Typical applications cover industrial automation production lines, robots, CNC machine tools, medical equipment, semiconductor manufacturing, packaging machinery, electronic assembly, and other scenarios that require high-precision motion control. There are also models in the same series such as S20330-SRS, S20360-SRS, S20660-SRS, S21260-SRS, S22460-SRS, S24860, etc., which can be flexibly selected according to power level and functional requirements.
In summary, S22460-SRS is a fully digital servo drive in the Colemorgen S200 series, with an 800 Hz speed loop bandwidth, 24 bit high-resolution feedback, SynqNet synchronization network, and plug and play debugging as its core. It is a mature solution that balances performance and usability in multi axis high-precision motion control scenarios.
