Description
DANAHER SERVO Driver S21260-SRS
KOLLMORGEN S21260-SRS is a compact brushless AC servo drive from the Colemorgen (now part of Danaher Group) S200 series, designed for low-power industrial automation scenarios.
DANAHER SERVO Driver S21260-SRS
In terms of core parameters, the continuous rated current is 12A RMS (40 ° C environment) or 8.0A RMS (50 ° C environment), the peak current is 18A RMS, the input voltage supports 120V AC or 240V AC, the rated power is about 1.5kW, the speed loop bandwidth is up to 800Hz, it supports 24 bit high-resolution encoder feedback, the protection level is IP20, and the working temperature range is -20 ° C to+60 ° C.
Functionally, it supports three control modes: position, speed, and torque, and can independently control multiple axes. The pre installed SynqNet tab supports real-time Ethernet motion control, and communication interfaces cover CANopen, RS-232/RS-485, EtherCAT, Profibus, Ethernet, etc. The built-in PLC function supports logic control and sequence control, as well as overcurrent, overvoltage, overheating protection, and fault diagnosis.
Typical applications include high-precision scenarios such as automated production lines, packaging machinery, robot joint drives, CNC machine tool feed control, semiconductors, and medical equipment.
Summary in one sentence: S21260-SRS is a medium power model of the S200 series, providing 800Hz high-speed response and 24 bit high-precision feedback in a compact size. It is a highly practical model for low-power servo applications.
