Description
SA9923A-E HIEE450964R0001- ABB Control Processor Module (AC800M Series)
=========Product identity=========
Brand: ABB (Sweden)
Model: SA9923A-E
Order number: HIEE450964R0001
Type: Controller Module/Central Processing Unit/Output Hybrid Module
System: ABB AC800M (Advant Controller 100)
SA9923A-E HIEE450964R0001 ABB High voltage frequency converter accessories
=========Core positioning=========
This is the controller host module in the AC800M system, with built-in CPU, power supply, and I/O interfaces. It can independently run control logic and also serve as a submodule carrier to expand communication functions. Essentially, it is “controlling the core+expanding the platform”.
=========Electrical parameters=========
Working voltage: 24V DC
Working current: 1A
Interface type: RS485
=========Physical parameters=========
Size: 100mm × 60mm × 30mm
Weight: Approximately 0.5kg
Installation method: DIN rail installation, supports hot swapping
Protection level: IP30
=========Core competencies=========
Execute complex control algorithms (PID, variable frequency/power frequency switching, multi pump cycle, flexible PWM)
Modular expansion, supporting up to 256 I/O points
Multiple communication interfaces: Ethernet RS485、Profibus、Modbus
Real time monitoring and diagnosis, supporting redundant configuration
Programming support: ladder diagram, functional block diagram, structured text
=========Application scenarios=========
Electricity, petroleum, chemical, metallurgical, water treatment, heating, gas, ports, manufacturing automation production lines
=========Similar related modules=========
SC560 (3BSE008105R1) – Controller Host ← Same Series
SC510 (3BSE003832R1) – Digital Input Module
SC610 (3BSE001552R1) – Digital Input+Communication submodule carrier
CI532- Communication module that can be plugged into SA9923A-E
