I. ABB NBRA-663 — Inverter Output Module
1. Product Overview
The NBRA-663 is a dedicated digital output module for ABB’s ACS800 series frequency converters , belonging to the ABB drive I/O expansion module family (NBRA-6xx series). Installed in the internal expansion slot of the ACS800 frequency converter, it provides the drive with additional digital output channels for controlling external devices such as relays, contactors, indicator lights, and solenoid valves.
This module is an original ABB industrial control spare part, widely used in variable frequency speed control systems that require multi-channel digital output control.
ABB NBRA-663 External Braking Chopper 600V
2. Core Technical Parameters
| parameter | Specification |
|---|---|
| brand | ABB (Original Import) |
| Applicable Drivers | ACS800 series (such as ACS800-37-0070-5, etc.) |
| Module type | Digital Output Module |
| Operating voltage | DC 24V |
| Output frequency | 50 kHz |
| Number of output channels | 8-channel digital output (relay output type) |
| Output format | Relay contacts (dry contacts) |
| Installation method | Insert into the internal expansion slot of the ACS800 frequency converter |
| Protection level | Meets the overall IP protection rating of the frequency converter |
| Certification | UL、CSA 等 |
3. Comparison of the NBRA-6xx series family
| model | Function | Channel type |
|---|---|---|
| NBRA-653 | Controller module | — |
| NBRA-653C | controller | — |
| NBRA-653-KIT | Input module kit | Digital input |
| NBRA-655 | Output module | Digital output |
| NBRA-655C | Output module | Digital output |
| NBRA-656 | — | — |
| NBRA-658C | controller | — |
| NBRA-659C | Input module | Digital input |
| NBRA-663 ⭐ | Output module | Digital output (8-channel relay) |
| NBRA-669C | — | — |
Typical Application Scenarios
| Application scenarios | Specific use |
|---|---|
| Multi-pump rotation control | The system uses 8 outputs to control the start and stop of 8 water pumps respectively. |
| Alarm Indication | Output fault signal to drive alarm light/buzzer |
| Valve control | Controlling the opening/closing of multiple electric valves |
| Process interlock | Implement security interlocking logic for multiple devices |
| Status feedback | Feedback on the inverter’s operating status (running/fault/ready, etc.) to the PLC. |
