KUC755AE105 3BHB005243R0105 ABB Driver power supply
KUC755AE105 3BHB005243R0105
Product Name: ABB KUC755AE105 Drive Power Board/Control Module
Brand: ABB
Series: KUC7 Series (KUC755AE101~KUC755AE108)
KUC755AE105 3BHB005243R0105 ABB Driver power supply
Product Type: High Voltage Variable Frequency Drive Power Board/Gate Pole Drive Power Supply Module/Excitation Control Module
Core function: Provide driving and control power supply for high-voltage frequency converter power units and generator excitation systems, while also undertaking functions such as gate drive power supply, pulse amplification, and excitation current control. Power supply for power units in high-voltage frequency converters such as ACS6000, and precise control of excitation current in Unitrol excitation system to ensure grid stability.
Input specifications: Main circuit 380-480 VAC three-phase; Control power supply 24 VDC ± 20%
Output specification: 480 VAC single-phase; 105 A; frequency 44-50 kHz
Efficiency/Power Factor: 94%/0.99
Size/Weight: 210 × 110 × 125 mm; Approximately 2.5 kg
Working temperature: -40 ° C~+70 ° C
Protection level: IP20
Installation method: Backpanel installation
Related models in the same series:
KUC755 AE101 (3BHB005243R0101) basic model, with lower output power
KUC755 AE102 (3BHB005243R0102) Standard Edition, General Scenarios
KUC755 AE103 (3BHB005243R0103) Enhanced version with redundancy function
KUC755 AE104 (3BHB005243R0104) old version, backward compatible
KUC755 AE106 (3BHB005243R0106) upgraded replacement, with consistent functional pins and optimized performance
KUC755 AE107 (3BHB005243R0107) High temperature type, -40 ° C~+85 ° C
KUC755 AE108 (3BHB005243R0108) High altitude type, suitable for distances above 4000m
ACS6000 associated spare parts:
3BHB004661R0101 (GUSP) system control power board
3BHB003041R0101 (IOEC) I/O Control Module
3BHE024855R0101 (UFC921A101) INT-2 interface board
3BHL000385P0101 IGCT power module
Application scenario: ACS6000 series high-voltage inverter drive power supply; Generator excitation system (Unitrol 5000, etc.); Industrial transmission fields such as large motor drives, rolling mills, and mine hoists; Wind power generation and photovoltaic power plant energy conversion management.
Product status: Active (not discontinued), in stock from the original factory and authorized channels.
