Description
DSQC322 3HAB5960-1 is a 16 channel relay output board in ABB industrial robot systems, belonging to the DSQC300 series I/O module, mainly suitable for robot controllers such as S4, S4C, and S4C+.
Core function: Convert the digital control signals of the robot controller into relay contact outputs for driving external execution devices such as solenoid valves, relays, indicator lights, small motors, etc. Each channel is an independent relay contact that supports switching between inductive and resistive loads and has overload protection capability.
ABB DSQC322 Circuit Board 3HAB5960-1
ABB DSQC322 Circuit Board 3HAB5960-1
Communication method: Connected to the IRC5 or OmniCore master controller through the system bus, belonging to the slave module, and addressed and scheduled uniformly by the controller.
Hardware features: Installed inside the robot control cabinet, industrial grade design, wide working temperature range, protection level IP20, compact size of about 234mm, weight of about 2 to 7kg, using screw terminal wiring, supporting plug and play replacement.
Typical application: In robot welding, handling, painting, palletizing and other production lines, it serves as a signal isolation and power amplification interface between the controller and on-site execution components. It is a standard I/O component in ABB robot systems that balances signal isolation safety and execution drive capability.
Summary in one sentence: DSQC322 3HAB5960-1 is a 16 channel relay output board for ABB robots, with bus communication, contact isolation drive, and installation inside the control cabinet as the core. It is the standard I/O interface for connecting robot systems to on-site execution equipment.
