ABB XVC770AE 3BHE006414R0001
ABB XVC770AE 3BHE006414R0001 Product Introduction
One sentence positioning: This is a high-performance analog controller module in the ABB AC 800M/System 800xA control system, which integrates signal acquisition, logic control, and multi protocol fieldbus communication. It is the core I/O node for achieving high-precision process control in DCS systems.
Product type: DCS controller module/Analog Control Board
Series: ABB AC 800M/System 800xA
Main model: XVC770AE
Part number: 3BHE006414R0001
ABB XVC770AE 3BHE006414R0001
Core functions:
Analog acquisition and processing: 8 configurable channels, supporting AI (analog input), AO (analog output), DI (digital input), DO (digital output) to be freely switched through software without the need for hardware replacement
High speed pulse input: additionally equipped with 2 high-speed pulse input channels, supporting a maximum counting frequency of 100kHz, suitable for high-frequency signal acquisition such as encoders and flow meters
High precision analog quantity: 16 bit resolution, AI channel accuracy of ± 0.1%, ensuring accurate measurement of process parameters
Fast digital response: The response time of the digital channel does not exceed 1 millisecond, meeting the requirements of fast logic control
Multi protocol communication: Supports industrial standard protocols such as PROFIBUS DP (up to 12Mbps), Modbus RTU, Modbus TCP, HART, etc., and can seamlessly interface with devices from different manufacturers
Electrical and Isolation:
The bus interface is electrically isolated from the channel, with an isolation voltage of not less than 1500V AC, effectively preventing on-site interference
Analog output supports 4-20mA or 0-10V configurable
Equipped with overcurrent, overvoltage, and reverse connection protection functions
Physics and Installation:
Installation method: S800 I/O rack plug-in installation, compact structure
Working temperature: -25 ° C to+70 ° C (wide temperature industrial grade design)
Support hot plugging, easy to maintain and replace online, without affecting system operation
Protection level: IP20 (module body, dependent on overall rack protection)
System compatibility:
Compatible with ABB AC 800M controller and S800 I/O station
Built in channel diagnosis, fault alarm, and status monitoring functions, supporting remote maintenance
Passed CE, UL, and SIL2 functional safety certifications
Typical application scenarios:
Power System: Monitoring and Control of Process Parameters in Thermal/Hydroelectric Power Plants
Metallurgical industry: precise control of temperature and pressure in blast furnaces and converters
Chemical/Petrochemical: Multi loop Control of Reactor Liquid Level, Flow Rate, and Temperature
Paper/Cement: Analog Quantity Collection and Adjustment in Continuous Production Processes
Oil and gas industry: remote SCADA data acquisition for pipeline stations
Current status: This model belongs to the ABB AC 800M/S800 series spare parts and is currently circulating in inventory on the market. If necessary, it is recommended to confirm compatibility with the existing AC 800M controller and S800 I/O rack, and refer to the physical nameplate data of the module for accuracy.
