ABB 500PSM03 Power Supply Module Product Introduction
One sentence positioning: This is an industrial grade switch power module that provides stable and efficient DC power for high-precision motion control equipment such as servo drives, controllers, and robots. It belongs to the compact DIN rail mounted power supply.
Product Type: Switched Mode Power Supply Module
Model: 500PSM03 (Related models in the same series: 500PSM03A, 1MRB150038 R1, 894-030375D, 136-011100H)
Series: 500PSM series industrial power supply
ABB 500PSM03 Power Supply Module
Core functions:
Convert AC input power into stable DC output to power servo drives, PLC controllers, robot joint drives, and other equipment
Ensure the continuity and stability of power supply for the motion control system under high-precision operating conditions
Electrical parameters (with 500PSM03A as the main reference model):
Input voltage range: 88~264 VAC (wide range AC input)
Output power: 100W
Conversion efficiency: up to 92%
Working temperature range: -25 ° C to+70 ° C
Protection function:
Overcurrent protection (OCP)
Overvoltage protection (OVP)
Undervoltage protection (UVP)
Short circuit protection (SCP)
Over temperature protection (OTP)
Active surge current limitation (soft start)
Physical parameters (500PSM03A):
Size: 20 mm x 125 mm x 50 mm
Weight: Approximately 2 kg
Installation method: DIN rail card mounting
Shell: Conformal coating, which can resist harsh industrial environments such as humidity and dust
Protection level: IP20
Compliant with EMC standards
Typical application scenarios:
Numerical Control Machine Tool (CNC): Provides stable power supply for servo drive and control systems
Industrial robots: support precise motion control of each joint
Automated production line: providing reliable power for equipment such as conveyor belts and robotic arms
process control system
machine control
Building automation
Heating, Ventilation, and Air Conditioning (HVAC)
lighting control
Current status: This model belongs to industrial spare parts and is circulating in the market in the form of inventory. Some versions may have been discontinued or gradually replaced by new series such as CP-S and CP-C.1. If necessary, it is recommended to confirm that the input and output parameters match the existing system and refer to the physical nameplate data of the module.
