Description
3BHE019719R0101 ABB Controller Module 5SHX1960L0006
BRAND AND OVERVIEW
Brand: ABB
Type: High-power semiconductor module / Integrated Gate-Commutated Thyristor (IGCT) assembly used in heavy industrial drive and power conversion systems.
ABB is a global technology leader in electrification, automation, and motion control, recognized for manufacturing highly reliable components for demanding industrial environments.
PART NUMBERS AND IDENTIFICATION
Material/Ordering Code: 3BHE019719R0101
Component/Type Code: 5SHX1960L0006
3BHE019719R0101 ABB Controller Module 5SHX1960L0006
Within ABB’s medium voltage drives and excitation systems, the 5SHX prefix designates an IGCT or a specialized gate driver power module assembly designed for precise, high-power switching.
TECHNICAL SPECIFICATIONS AND PARAMETERS
Component Type: Asymmetrical IGCT / Power Semiconductor Module.
Voltage Rating: Designed for medium voltage applications, typically operating in the kilovolt (kV) range.
Current Capacity: High current handling capability, engineered for heavy-duty industrial switching.
Control Interface: Integrated gate drive unit utilizing optical fiber connections to eliminate electromagnetic interference (EMI).
Cooling: Engineered for advanced cooling configurations, such as liquid-cooled systems or heavy-duty heatsink mounting, to manage high thermal dissipation.
Efficiency: Optimized for low turn-on, turn-off, and conduction losses to maximize overall system efficiency.
TARGET INDUSTRIES
This module is built for heavy industries requiring precise, high-capacity electrical control:
* Metals and Mining: Used in main drives for rolling mills, mine hoists, and conveyors.
* Marine and Offshore: Integrated into marine propulsion systems and thruster drives for large vessels.
* Power Generation and Utilities: Utilized in wind turbine converters, pumped-storage hydro plants, and Static Synchronous Compensators (STATCOMs) for grid stability.
* Oil, Gas, and Petrochemicals: Deployed in large compressors, pumps, and fans.
* Chemical Processing: Used in high-power electrolysis and large-scale processing drives.
APPLICATION SCENARIOS
The module is typically embedded within larger ABB automation and drive systems, such as ACS series medium voltage drives or UNITROL excitation systems, for the following scenarios:
* Medium Voltage AC Drives (MVD): Serving as the core switching element in frequency converters to control the speed and torque of large multi-megawatt motors.
* Flexible AC Transmission Systems (FACTS): Acting as a high-speed electronic switch in power quality systems to stabilize grid voltage and balance reactive power.
* Generator Excitation Systems: Managing the field winding currents of large synchronous generators in power plants to control output voltage.
* Power Grid Conversion: Assisting in sub-stations for power conversion and energy transmission management.
