Schneider Electric C400/A8/1/1/1/10 | Motion Controller Spec Sheet
Product Introduction
When a high-speed packaging machine drops offline due to a processor fault on the main control rack, sourcing an exact-match unit is the only way to avoid weeks of costly line restructuring. The Schneider Electric C400/A8/1/1/1/10 is not a generic programmable logic block; it is an integrated motion controller engineered to handle complex, multi-axis kinematic calculations for demanding industrial automation machinery.
Seated directly in the control cabinet backplane, the unit processes high-frequency motion trajectories and communicates seamlessly with connected servo drives through a deterministic real-time interface. It demands clean 24VDC power and strict cabinet grounding guidelines, but once commissioned, it delivers the precise synchronization required for high-throughput manufacturing cells.
C400/A8/1/1/1/10
Key Technical Specifications
| Parameter | Specification |
| Processor Architecture | High-performance industrial CPU core |
| System Memory | Integrated RAM & non-volatile flash storage |
| Nominal Input Voltage | 24VDC (+/- 20\%) |
| Drive Capacity | Multi-axis SERCOS interface support |
| Communication Ports | Ethernet, RS232, RS485, CANopen, PacNet |
| Operating Temperature | 0^\circC to 55^\circC ambient |
| Mounting Type | Central control cabinet rack slot |
| Weight | Approximately 1.2 kg |
Application Scenarios & Pain Points
- Automated Packaging Lines: Periodic bus timeouts used to plague older multi-axis wrappers until maintenance teams upgraded to a verified controller card. Swapping in the C400/A8/1/1/1/10 eliminated jitter thanks to its stable internal clock processing.
- Form-Fill-Seal Systems: Without deterministic loop updates, camming profiles drift out of alignment over multi-shift runs. This PacDrive unit maintains strict synchronization across axes, preventing mechanical binding.
- Legacy System Modernization: A bottling plant avoided a complete software rewrite by dropping the C400/A8/1/1/1/10 directly into an existing Elau rack architecture, restoring production in hours.
QA & Live Testing SOP (Trust Signal)
Legacy automation hardware demands rigorous verification before installation. Every incoming Schneider/Elau C400/A8/1/1/1/10 goes through a strict multi-point test protocol:
- Visual & Optical Inspection: We check internal board components for thermal wear, examine backplane connector pins for oxidation, and verify memory card integrity.
- Powered Bench Verification: The unit is mounted to a live test rack, supplied with nominal 24VDC, and subjected to a simulated communication handshake across its network ports.
- ESD-Safe Packaging: Units are sealed in heavy-duty moisture-barrier antistatic bags. When you unbox this controller, it is ready for immediate critical-path deployment.
Field Engineer’s Pitfall Guide
- ❗ Memory Card Data Corruption: Never pull or swap the system memory card while the C400/A8/1/1/1/10 is powered on; doing so will corrupt the boot sector and wipe the loaded motion project files.
- ❗ SERCOS Ring Continuity: Failing to verify optical fiber cleanliness or breaking the ring topology order will trigger immediate drive communication faults on startup.
- ❗ Firmware Revision Mismatches: Always back up your project configuration via engineering software before swapping controllers to match the exact runtime firmware revision.
Intent-Driven FAQ
Can I hot-swap the Schneider Electric /A8/1/1/1/10 while the cabinet is powered?
No. Cutting main 24VDC power to the rack is mandatory before inserting or removing the controller to protect sensitive internal bus drivers and memory components.
Is this specific /A8/1/1/1/10 unit brand new?
This inventory consists of verified surplus—un-installed factory backup stock preserved in climate-controlled storage environments.
What software is required to program and configure this controller?
Configuration and logic deployment require the legacy EPAS/PacDrive engineering software environment along with appropriate communication cables.
What kind of warranty comes with this purchase?
Every surplus PacDrive controller includes a standard 1-year functional replacement warranty covering any operational defects under normal conditions.
Does the unit come with the system memory module included?
Yes, the unit ships with the standard system memory populated, though restoring your specific machine application backup file via software will still be required upon installation.
