Fireye 85UVF1-1CEX | Explosion-Proof UV Flame Detector
Dynamic Product Introduction
Combustion loop interruptions and spurious burner trips on industrial boilers or process heaters frequently stem from degraded sensor optics or failing internal electronics within aging flame scanners. When an older ultraviolet detector loses sensitivity or struggles to discriminate between true combustion and hot refractory glow, routine cleaning rarely resolves underlying microchip or photodiode wear. Deploying the Fireye 85UVF1-1CEX resolves this safety-critical constraint directly, introducing a factory-spec explosion-proof scanner engineered to restore absolute discrimination and reliable flame monitoring.
In critical plant retrofit scenarios, mounting this exact replacement unit re-establishes strict burner management compliance without forcing an expensive, full-scale control system rewiring. (Though verifying sighting alignment, cooling air purge pressure, and spectral matching prior to light-off remains essential.) It handles severe hazardous-area environments cleanly, keeping high-capacity industrial furnaces and utility boilers running safely.
85UVF1-1CEX
Key Technical Specifications
| Technical Parameter | Specification Detail |
| Device Category | Explosion-Proof Integrated UV Flame Scanner |
| Series Compatibility | Fireye Phoenix Series 2 Burner Management Architecture |
| Sensing Technology | Solid-state ultraviolet (UV) radiation detection cell |
| Spectral Response | Tuned to hydrocarbon combustion wavelengths |
| Hazardous Area Rating | Ex d IIC T6 ( ATEX / IECEx certified variants) |
| Enclosure Protection | Heavy-duty cast aluminum housing (NEMA 4X / IP66 equivalent) |
| Standard Outputs | Internal flame relay (SPST) and 4-20mA analog flame strength signal |
| Supply Voltage | 24 VDC nominal |
Global Sourcing & Live-Test SOP (Transparency Core)
Procuring critical combustion safety hardware demands rigorous optical and electrical validation to guarantee fail-safe operation in hazardous zones.
- Inbound Verification: Incoming scanners undergo serial tracking, OEM label inspection, and anti-counterfeit batch checks against historical Fireye production ledgers.
- Live Simulation: Qualified units are mounted onto a specialized optical test rig to evaluate UV frequency response, flicker recognition, and internal relay switching thresholds.
- Diagnostics: Technicians execute electronic self-check verification, signal amplification sweeps, and 4-20mA output linearity checks to catch latent component drift.
- Final Prep: Optical lenses are polished and inspected, and units are sealed inside heavy-duty anti-static and moisture-barrier packaging to ensure pristine delivery.
The Field Engineer’s Pitfall Guide
❗ Sighting Tube Misalignment and Hot Refractory Glare: Pointing the scanner directly at glowing refractory brick rather than the primary flame envelope can trick lower-quality sensors, but failing to properly align the 85UVF1-1CEX along the optimal line of sight will cause weak signal detection. Always use a sighting tube aligned to view both the pilot and main flame intersection.
❗ Inadequate Purge Air Pressure: Operating explosion-proof scanners in dusty or high-soot environments without maintaining continuous positive purge air pressure will quickly foul the optical lens, triggering nuisance flame-out trips. Always verify purge flow before energizing the burner.
❗ Hazardous Area Grounding Omissions: Neglecting to connect an external ground wire to the designated functional ground screw on the scanner end plate can compromise explosion-proof safety integrity and invite electrical noise interference. Always ensure proper earth bonding.
Intent-Driven FAQ
Will this 85UVF1-1CEX scanner mount directly onto my existing Fireye mounting flange?
Yes, the unit utilizes standard Fireye Phoenix threaded mounting interface dimensions, ensuring a direct mechanical fit on compatible burner sighting assemblies.
Are these safety-critical flame scanners factory sealed or certified surplus stock?
We maintain strict inventories of both factory-sealed OEM surplus and fully recertified, bench-tested units. Each listing explicitly details the precise condition tier to match your plant’s safety rules.
What environments are certified for the “CEX” explosion-proof housing model?
The CEX variant is specifically engineered and certified (such as ATEX/IECEx Ex d IIC T6) for direct installation in classified hazardous process areas where explosive gas atmospheres may be present.
What kind of warranty coverage is included with this replacement scanner?
Every unit is backed by our comprehensive operational warranty, covering electrical component health, optical sensor integrity, and relay switching reliability from day one.
How do I monitor real-time flame signal strength during setup?
The built-in 4-20mA analog output provides continuous feedback regarding relative flame signal intensity, allowing technicians to optimize alignment and track signal degradation over time.
