XVC724BE102 3BHE009017R0101 ABB Board
ABB XVC724BE102 (Order Number: 3BHE009017R0102)
XVC724BE102 3BHE009017R0101 ABB Board
This is a processor module produced by ABB, belonging to the ABB XVC724BE series of medium and high voltage frequency converter matching boards. It is brand new and original, and is produced in Sweden.
Core functions:
This board is essentially a high-performance processor module, mainly used for the main control of medium and high voltage frequency converters. It integrates functions such as voltage regulator with PID filter (automatic mode), excitation current regulator with PI filter (MAN mode), reactive and/or active current drop compensation, limiter circuit (ensuring generator operates within safe range), power factor/reactive load control, and power system stabilizer (PSS). The hardware adopts a 32-bit ARM Cortex-M3 processor, equipped with 2GB DDR3 RAM and 128MB flash memory to ensure data processing and storage capabilities. The communication interfaces include Ethernet, CAN, and RS-485, which can be connected to DCS or PLC systems for remote monitoring and parameter adjustment.
Key technical parameters:
The working temperature range is -40 ° C to+70 ° C, and the operating height can reach 4000 meters, suitable for harsh industrial environments. It has multi-channel digital input (supporting high-speed sampling, filtering, and debounce), analog input/output, as well as multiple protection functions such as overcurrent, overvoltage, and undervoltage. The power supply is 24V DC standard industrial power supply, with dimensions of approximately 58 × 58 × 58mm and anti vibration and dust-proof design.
Typical application scenarios:
Mainly used for the main control of ABB medium and high voltage frequency converters, driving large motors and generators, widely used in power transmission and distribution systems in industries such as electricity, petroleum, chemical, metallurgy, mining, and nuclear power. It can also serve as a processor module for ABB 800xA DCS systems, responsible for on-site signal acquisition, processing, and communication hub roles.
Summary: XVC724BE102 is the core processor module in ABB’s industrial control system, integrating various power control functions such as voltage regulation, excitation control, reactive power compensation, and system stability. It is an indispensable main control unit in medium and high voltage frequency conversion and DCS systems. If used for system maintenance or spare parts procurement, it is recommended to confirm the specific compatible inverter model (ACS8000 series or 800xA DCS) to ensure compatibility.
