Description
ABB XVC517AE10 3BHB004744R0010 Module
ABB XVC517AE10 (Order Number: 3BHB004744R0010)
ABB XVC517AE10 3BHB004744R0010 Module
This is a Gate Drive Unit module produced by ABB, belonging to the ABB XV C517 series, originating from Sweden, and is brand new and original.
Core functions:
This board is essentially a power device driver module, mainly used to drive power semiconductor switching devices such as IGBT or MOSFET. It receives low-voltage logic signals from the controller, converts them into high-voltage high current drive signals that can quickly switch power devices, and has fault detection, short-circuit protection, and status feedback functions. Undertake the role of controlling motors, driving power equipment, and achieving precise speed and position control in the system. It can also serve as an interface module in ABB frequency converters or DCS systems, connecting the controller to the power main circuit.
Key technical parameters:
Rated power 7.5kW, input voltage 380V AC, output voltage 0-380V AC, output frequency 0-60Hz, maximum current 20A. Operating temperature -10 ° C to+40 ° C, storage temperature -20 ° C to+60 ° C, protection level IP20. The power supply is 240V DC, designed with a modular structure, resistant to vibration and dust, and suitable for industrial chassis installation. The size is approximately 480mm x 240mm x 180mm, and the weight is approximately 15kg.
Typical application scenarios:
Mainly used as a gate drive interface for power devices in ABB ACS800/ACS880 series frequency converters, controlling the speed and torque of AC motors. It is also widely used in servo motor drives for industrial automation production lines, large-scale industrial motor control, as well as power conversion and motor control systems for industries such as electricity, petroleum, chemical, metallurgy, mining, and rail transit.
Summary: XVC517AE10 is a gate drive module in ABB’s industrial control system. Its core value lies in converting the weak current signal of the controller into a strong drive signal sufficient to quickly switch power devices. It is a key hub connecting the control layer and power layer in the frequency converter and motor drive system. If used for system maintenance or spare parts procurement, it is recommended to confirm the specific compatible inverter model (ACS800 or ACS880) to ensure compatibility.
