Description
ABB TC514V2 3BSE013281R1 optical relay modem
TC514V2 3BSE013281R1
ABB AF100 twisted pair to fiber optic repeater | Advant OCS/Symphony Plus
[System]
ABB Advant Controller 450 / AC 460
ABB Symphony Plus Distributed Control System (DCS)
ABB System 800xA v5.1+
ABB TC514V2 3BSE013281R1 optical relay modem
Module positioning
TC514V2 belongs to the ABB Advant Fieldbus 100 (AF100) series media converter, with the core function of achieving bidirectional signal conversion between twisted pair cables and optical fibers in the AF100 fieldbus network. It is a pure communication interface board and does not have logic processing or I/O functions.
[Core Function]
⊙ Signal conversion: AF100 twisted pair cable ↔ Fiber optic, bidirectional transparent transmission
⊙ Distance Expansion: Breaking through the limitations of copper cable transmission, fiber optic links can significantly extend communication distance
⊙ Anti interference: Fiber optic transmission is completely immune to electromagnetic interference (EMI), suitable for high noise industrial environments
Network Expansion: Connect controllers, communication modules, and remote I/O devices to expand AF100 bus links
Transparent forwarding: completely transparent to the AF100 protocol, without modifying communication content
[Technical Specifications]
Bus protocol: Advant Fieldbus 100 (AF100)
Conversion medium: twisted pair cable ↔ single-mode fiber
Power supply: 24V DC, uniformly powered by DCS backplane
⊙ Power consumption: approximately 2-3W
Working temperature: -20 ° C~+60 ° C (industrial grade wide temperature design)
Protection level: IP20 (indoor installation)
Installation method: DIN rail installation
⊙ Size: 168mm × 122mm × 58mm
Weight: Approximately 0.34kg
Certification: CE, UL, CSA
[Associated Model]
Same series: TC514V1 (early version), TC514V3 (upgraded version)
Similar functions: TC630 (coaxial to fiber optic modem), TC515V2 (twisted pair repeater)
Communication support: UAA326A04 (serial communication module), CI801/CI840 (Ethernet/fiber optic communication module)
Engineering tools: Composer (Advant/Symphony Plus programming software), Control Builder M (800xA engineering tool)
Typical application scenarios
Fiber optic link expansion of AF100 bus in power plant DCS
Industrial environments with severe electromagnetic interference (near frequency converters and large motors)
Remote communication between the main control room and the remote I/O cabinet
Key process control scenarios that require high reliability communication links
[Precautions for use]
This module is a pure communication board and cannot be used as a substitute for controllers or I/O modules
When replacing, it is necessary to confirm that the model is completely identical (3BSE013281R1/TC514V2). Different variants result in different interface configurations and cannot be mixed
When wiring optical fibers, attention should be paid to avoiding excessive bending, and the minimum bending radius of the optical cable should comply with the specifications
The market for this model is mainly based on inventory and disassembled parts. When purchasing, it is recommended to prioritize confirming the reliability of spare parts sources and checking system compatibility (Advant OCS/AC 460/Symphony Plus platform)
Installation and commissioning must be carried out by engineers with ABB DCS maintenance qualifications
