Description
ABB SC560 3BSE008105R1- ABB Automation Controller Module/submodule Carrier (AC800M Series)
【 Basic Information 】
Brand: ABB (Sweden)
Model: SC560
Order number: 3BSE008105R1
Type: Programmable controller host+submodule carrier
System: ABB AC800M series (Advant Controller 100)
Output frequency: 30kHz
Customs code: 85389091
ABB SC560 3BSE008105R1 Module
[Product Positioning]
SC560 is the basic controller host in the AC800M system, with built-in CPU, power supply, input/output, and program memory. It can independently run control logic or serve as a submodule carrier to accommodate communication modules such as CI532, enabling data exchange between devices. Essentially, it is a combination of “control core+extension platform”.
【 Main Features 】
High performance processing: capable of quickly executing complex control algorithms and logic, supporting PID control, frequency converter/power frequency switching, multi pump cycle operation, flexible PWM (lower noise)
Modular expansion: can connect expansion units, expansion power units, function expansion boards, special adapters, etc., with a maximum I/O expansion of 256 points (up to 8 special expansion units), and a total of 384 points with CC Link remote I/O
Multiple communication interfaces: Supports Ethernet, serial port, Profibus, Modbus, etc., with built-in RS485 communication port
High reliability: Industrial grade design, supporting redundant configuration, real-time monitoring and diagnostic functions
Programming support: ladder diagrams, functional block diagrams, structured text, etc
[Physical Parameters]
Net depth: 486mm
Net height: 27mm
Net width: 288mm
Net weight: approximately 0.76kg
Installation method: DIN rail installation, supports hot swapping
【 Application Fields 】
Modern industrial fields such as electricity, petroleum, mining, ports, heating, gas, water supply, sewage treatment, metallurgy, papermaking, textile, chemical, water conservancy, as well as manufacturing automation production lines, process monitoring, energy management, building automation, traffic signal control, etc.
【 Related modules of the same series 】
SC510 (3BSE003832R1) – Digital Input Module
SC520 (3BSE003816R1) – Digital Input Module
SC520M (3BSE016237R1) – submodule carrier
SC610 (3BSE001552R1) – Digital Input+Communication submodule carrier
CI532- Communication module that can be plugged into SC560
【 Precautions 】
This module is often labeled as “servo axis control module” or “communication board”, more precisely, it is the controller host and submodule carrier of the AC800M system. The version above 75kW comes with a DC reactor randomly. When purchasing, please refer to the model SC560+order number 3BSE008105R1 to confirm whether it needs to be used with communication modules such as CI532.
