ABB DSTA121A 57120001-NY-1 CONNECTION MODULE
Introduction to ABB DSTA121A 57120001-NY-1 Analog Module
ABB DSTA121A 57120001-NY-1 is an analog input module in the ABB System 800xA/ADVANT-800XA DCS control system S800 I/O series. It is a key interface module used in process control systems to collect continuous process signals and is widely used in DCS control circuits in industries such as power, petrochemicals, metallurgy, and water treatment.
ABB DSTA121A 57120001-NY-1 CONNECTION MODULE
core positioning
This module is designed specifically for multi-channel analog signal acquisition and is an analog input unit in the S800 I/O series. It is responsible for converting the 4-20mA or 0-10V DC standard signals output by field sensors (such as temperature transmitters, pressure transmitters, flow meters, etc.) into digital quantities that can be processed by the controller. It is the core component of the process variable acquisition layer.
Basic Parameters
Material Number: 57120001-NY-1
Model: DSTA121A
Number of channels: 8 independent analog input channels
Input signal type: 4-20mA DC (current input)/0-10V DC (voltage input), can be selected through bus configuration
Input impedance: Approximately 250 Ω for current input and approximately 10k Ω for voltage input
Measurement accuracy: ± 0.1% FS (full scale)
Resolution: 16 bit A/D conversion
Channel update rate: typical value of 1 second
Sampling period: 100ms
Communication interface: Modulus Bus, compatible with Profibus DP
Working voltage: 24V DC
Typical power consumption: about 2W
Electrical isolation: Channel isolation ≥ 1500V, module bus isolation ≥ 1500V
Protection level: IP20, suitable for installation inside control cabinets
physical properties
Size: Approximately 102mm × 119mm × 45mm (S800 series standard size)
Weight: Approximately 0.25kg
Working temperature: -30 ° C to+60 ° C
Storage temperature: -40 ° C to+85 ° C
Installation method: Standard DIN rail installation, to be used in conjunction with TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850 and other terminal units to ensure electrical isolation performance
Main functional features
Multi signal type support: Each channel supports current (4-20mA) or voltage (0-10V) input, which can be parameterized and configured through the bus to flexibly match different on-site transmitter requirements. It can adapt to multiple signal types without the need to replace hardware.
High precision acquisition: 16 bit A/D resolution, good linearity, suitable for process control circuits that require high measurement accuracy, such as precise acquisition of analog quantities such as temperature, pressure, flow rate, liquid level, etc.
Loop monitoring: supports the detection of abnormalities such as open circuit, short circuit, and over range in input signals. Fault information can be reported to the main controller through the Modulus Bus and displayed on the CPU LCD screen for quick identification of the fault channel.
Multiple protection: Built in overload protection, short circuit protection, and over temperature protection. In case of a fault, the output of the channel will be automatically cut off and reported to the bus, reducing the risk of shutdown.
Channel status indication: Each channel is equipped with LED indicator lights, which can quickly determine the working status of the channel without the need for additional diagnostic tools.
Parameterized configuration: Supports configuring channel filtering time through the bus (with multiple options), effectively suppressing high-frequency noise interference on site and improving signal acquisition stability.
Hot plug support: Supports online hot plug replacement, maintenance can be completed without cutting off the power supply of the I/O station system, reducing downtime.
Start self check: Automatically check the electrical ID of the module when powered on, and do not enter the running state when it does not match the configuration, to prevent control abnormalities caused by mismatches.
Version Description
NY-1 is a specific revised version of this module, which has been optimized and upgraded in firmware or hardware compared to earlier versions such as NY. When a version upgrade is required, the corresponding upgrade kit should be used, and it is not recommended to directly replace across versions to ensure compatibility.
Comparison with modules of the same series
DSAI146 (57120001-R1) is a 31 channel Pt100 temperature analog input with high channel density, designed specifically for large-scale temperature acquisition. DSAO130A (57120001-ACX) is a 16 channel analog output used to drive actuators. DSTA121A is an 8-channel universal analog input with a moderate number of channels and flexible signal types (current/voltage optional), suitable for medium-sized analog acquisition scenarios, such as multi parameter monitoring of a single circuit or process variable acquisition of small and medium-sized devices. This is the essential difference between it and other S800 analog modules.
Typical application scenarios
Power industry: Collection of process variables such as temperature, pressure, and flow rate for auxiliary systems of generator sets.
Chemical industry: Monitoring of analog signals such as reactor liquid level, pipeline pressure, and medium flow rate.
Metallurgical industry: Collection of analog process parameters such as blast furnace air temperature and rolling mill hydraulic pressure.
Water treatment: analog monitoring of boiler feedwater flow rate, steam pressure, effluent quality, etc.
HVAC: Collection of analog quantities such as chilled water temperature and supply air pressure.
