ABB 5SHX0660F0002 Smart Module Product Introduction
Product Name: ABB 5SHX0660F0002 Semiconductor Controlled Silicon Converter Intelligent Module
Brand: ABB (Swiss ABB Group)
Series: ABB DCS Smart Module Series
Product type: Thyristor/SCR rectifier intelligent power module, with built-in trigger control and rectification functions, belonging to the core power control component of ABB medium voltage DC speed regulation system.
ABB 5SHX0660F0002 Smart module
Core functions:
This module is equipped with two thyristor rectifiers, which are responsible for rectifying AC power into controllable DC output and achieving 0-100% stepless voltage regulation through analog or digital signals. It is widely used in DC motor speed regulation, industrial heating control, power dimming and other scenarios. As a Smart Module, it supports programmable control logic and can seamlessly integrate with ABB DCS systems or other controllers to achieve remote monitoring and automated adjustment.
Key electrical parameters:
Rated current: 60A
Controllable range: 0-100%
Trigger modes: positive pulse trigger, negative pulse trigger, zero voltage switch (three options available)
Control mode: Analog control (0-10V/5-24V), digital control
Control signal current: 5-20mA
Switching frequency: 15-50kHz
Efficiency: greater than 95%
Power factor: greater than 0.95
Power supply voltage: 24-55V DC
Insulation level: Class B
Physical parameters:
Size: 87mm x 46mm x 23mm
Weight: 0.14kg
Installation method: DIN rail installation
Cooling method: air cooling/water cooling (two options available)
Product certification: CE, UL, CQC
Core features:
High efficiency: Efficiency greater than 95%, power factor greater than 0.95, and extremely low energy loss
Wide control range: 0-100% infinitely adjustable, can be precisely controlled with analog or digital signals
Multiple triggering methods: Supports three types of triggering: positive pulse, negative pulse, and zero voltage switch, adapted to different load characteristics
High reliability: Using high-quality components and advanced technology, it has good anti vibration and anti impact capabilities, and a long service life
Easy integration: standard rail installation, rich communication interfaces, easy to interface with ABB DCS and third-party control systems
Smart Programmable: Supports user-defined control logic to meet diverse industrial control needs
Typical application scenarios:
DC speed control system: As the core power module of the medium voltage DC speed control cabinet, it controls the speed of the DC motor and is applied to heavy equipment such as rolling mills, mine hoists, and ship propulsion
Industrial heating control: power regulation of resistance heaters and induction heaters to achieve precise temperature control
Electric dimming system: stepless brightness adjustment for stage lighting and industrial lighting
Power transmission and distribution: reactive power compensation and power factor correction devices for the power grid
Welding equipment: Welding current and voltage control of arc welding machine
AGC system: automatic thickness control in precision processing such as aluminum foil rolling
New energy field: DC power conversion in charging piles and photovoltaic energy storage systems
Compatible systems:
Mainly used in conjunction with ABB medium voltage DC speed control devices (ACS series) and DCS distributed control systems, it can also be integrated into third-party automation control platforms.
