Description
3BHE014185R0001 UUD148AE01 ABB module
3BHE014185R0001 UUD148AE01
Product Name: ABB UUD148AE01 3BHE014185R0001 Programmable Automation Controller (PAC) Module/Interface Module
Brand: ABB
Series: ABB AC 800M Controller Series/Advant OCS Distributed Control System
3BHE014185R0001 UUD148AE01 ABB module
Product type: High performance programmable automation controller module, with interface module function, suitable for industrial automation control scenarios
Core function: As the on-site intelligent control core in ABB distributed control system, responsible for executing complex control logic, real-time data acquisition and processing, and multi protocol communication management. Built in independent controller logic can quickly process input/output signals from on-site devices, reducing the burden on the main control station. As an interface bridge between systems, it supports seamless integration with old control systems and is commonly used for interface upgrades in renovation projects.
Hardware configuration:
Processor: PowerPC multi-core CPU, with a clock speed of 500MHz
Memory: 128MB RAM+512MB Flash, supports storage expansion
Instruction cycle: ≤ 10ms
Scalability: Supports S800/S900 series I/O module expansion
Communication interface:
Ethernet: 2 × 10/100Mbps
Serial port: 1 × RS232/RS485
Fieldbus: compatible with mainstream industrial protocols such as Modbus TCP/IP, Profibus DP, OPC UA, etc
Fiber optic interface: supports Module Bus fiber optic communication, connecting to CI801 or CI840/CI840A controllers
I/O capability:
Maximum support for 8192 I/O points
Supports simultaneous processing of 32 parallel tasks
Supports multiple signal types such as digital input/output, analog input/output, pulse input, etc
Electrical parameters:
Power supply voltage: 24V DC ± 10%
Typical power consumption: 12W, maximum power consumption: 15W
Insulation strength: 1500V AC/1min
Physical parameters:
Size: 200mm x 120mm x 75mm (width x height x depth)
Weight: Approximately 1.2kg
Installation method: 35mm DIN rail installation
Protection level: IP20
Shell material: aluminum alloy, excellent heat dissipation performance
Work environment:
Working temperature: 0 ° C to+60 ° C (some data indicate -25 ° C to+70 ° C)
Storage temperature: -40 ° C to+85 ° C
Relative humidity: 5% to 95% (no condensation)
Software and Programming:
Development environment: Control Builder M Professional
Programming standard: IEC 61131-3, supports LD (ladder diagram), FBD (function block diagram), ST (structured text), SFC (sequential function diagram), IL (instruction list)
Operating System: VxWorks Real time System
Certification
CE Certification
RoHS Compliance (Directive 2011/65/EU)
WEEE Compliance (Directive 2012/19/EU)
Hazardous Area: Class 1 Zone 2/ATEX Zone 2
Classification Society Certification: ABS, BV, DNV-GL, LR
Typical application scenarios:
Process industry: automation control of chemical, petroleum, natural gas and other processes
Discrete Manufacturing: Production Line Control, Machine Control, Assembly Operations
Energy management: power plant monitoring, transmission line management, water treatment plant control
Building Automation: Building Automation, Air Conditioning Systems, Lighting Control
System transformation: Upgrading and replacing the old control system as an interface device between the old and new systems
Related models in the same series:
UUD148AE02 (3BHE014185R0002): Same series but different versions
CI801: UUD148AE01 upper layer controller that can be connected
CI840/CI840A: UUD148AE01 upper layer controller that can be connected
TB820/TB820 v2/TB840/TB840: Supporting I/O communication terminal module
NTAM-01, NCLM-01, NKLS11-3: AC 800M system supporting I/O module
