Product Name: ABB LTC743CE02 3BHE013299R0002 Power Module/Fiber Optic Communication Interface Module
Brand: ABB
Series: LTC743CE02 series, belonging to ABB AC800M/S800/S600/S100 I/O series and UNITROL excitation system supporting modules
3BHE013299R0002 ABB LTC743CE02
Product type: 24V DC power module, integrated fiber optic communication interface (Module Bus fiber port), with both power supply and communication functions
Core function: As a power supply and communication bridge device for on-site I/O nodes in ABB distributed control systems, it provides stable 24V DC power supply for on-site I/O modules, and realizes fiber optic ring network communication of Module Bus through fiber optic interfaces, connecting CI801 or CI840/CI840A controllers to achieve transparent data transmission with I/O clusters. Supports two network topologies: simple optical configuration (ring) and duplex optical configuration (line).
Communication interface:
1 fiber optic port, transmitter/receiver rate of 10 Mbit
Support plastic fiber optic (PCS) and hard silicon fiber optic (HCS)
Communication protocol: Module Bus fiber optic protocol
Connection objects: CI801, CI840, CI840A controllers, communicate with the I/O cluster through TB820/TB820 v2/TB840/TB840
Electrical parameters:
Input voltage: 24V DC
Redundant power supply: supports dual power redundant input
Protection level: IP20
Physical parameters:
Dimensions: Width 17.6mm x Height 56.7mm x Depth 42.3mm
Weight: Approximately 90g
Installation method: 35mm DIN rail installation
Work environment:
Working temperature: 55 ° C for horizontal installation, 40 ° C for vertical installation
Storage temperature: -25 ° C to+70 ° C
Equipment category: Class I (IEC 60536)
Certification
CE Certification
RoHS Compliance (Directive 2011/65/EU)
WEEE Compliance (Directive 2012/19/EU)
Hazardous Area: Class 1 Zone 2/ATEX Zone 2
Typical application scenarios:
ABB AC800M processor system
ABB S800 I/O series
ABB S600/S100 I/O series
UNITROL 5000/UNITROL 6000 Static Excitation System
Industrial automation scenarios such as power plant DCS control, chemical process control, and metallurgical production lines that require fiber optic redundant communication
Related models in the same series:
Other versions of LTC743CE02 series
UFC921A101 (3BHE024855R0101): ABB power module, same series application
PPC907BE (3BHE02457R0101): ABB power module, same series application
SYN5202A: ABB synchronous device, used in conjunction with this module
NDPI-02 (58914444): ABB I/O module, compatible with the system
