ABB 216EA62 1MRB150083R1/F 1MRB178066R1/F Product Introduction
One sentence positioning: This is the core electronic module in the ABB REG 216 protection system, belonging to the data acquisition and I/O interface conditioning unit, used for industrial process protection control, with analog acquisition, digital processing, temperature measurement, and communication networking capabilities.
216EA62 1MRB150083R1/F 1MRB178066R1/F ABB Module
Product type: Protection system electronic module (plug-in unit)
System: ABB REG 216 protection system (rack model 216MB62)
Part number: 216EA62 is the main model, and 1MRB150083R1/F and 1MRB178066R1/F are two interchangeable part number versions with the same function
System architecture description:
The REG 216 protection system consists of at least one 216MB62 electronic equipment rack, with electronic modules inserted into the rack from the front in the form of plug-in units. The communication between various electronic units inside the rack is achieved through the B448C parallel bus, which is installed at the rear of the rack. There are also standard cable interfaces at the rear for connecting I/O units and printer connectors. The input transformer, auxiliary relay I/O, and trip relay unit are installed on the inside of the rear panel of the protection cabinet.
Core functions:
Data acquisition, storage, and processing: Accurately measure various analog quantities, support A/D and D/A conversion, and control and adjust analog quantities through I/O modules. The number of bits and accuracy can be selected according to requirements
Temperature measurement interface: can directly connect various thermal resistors or thermocouples to achieve real-time monitoring of environmental temperature
Communication interface: equipped with standard hardware interfaces, supporting Modbus master/slave (serial port or TCP/IP), TCP/IP, UDP/IP, ICMP, SNTP network time synchronization, TSAA IP multicast, Trimble GPS timing (connected to GPS antenna through serial port # 1), Jet Direct network printing, embedded OPC server
Digital quantity processing: can convert digital quantities into 0-10V or 4-20mA analog output, with programmable control function
Distributed control network construction: It can be used in conjunction with multiple PLCs to form a centralized management and decentralized control distributed control network, achieving effective control of large-scale complex systems
Communication port details:
Serial Port # 1: Supports Modbus or Trimble GPS interfaces
Serial port # 4: Supports Modbus or TriStation interfaces
Four serial ports aggregate data rates up to 460.8 Kbps
The entire Tricon system supports up to 32 Modbus master or slave stations (including network and serial ports)
Physical parameters:
Shell protection level: IP20
Installation method: Plug in, insert from the front into the 216MB62 rack
Supports online replacement, does not support hot standby
Typical application scenarios:
Process protection control systems for industries such as power plants, steel mills, oil and gas, petrochemicals, papermaking, cement, and ships. Integrate with sensors, actuators, and other automation equipment to achieve control and management of automated production lines.
Current status: This model belongs to the early REG 216 series spare parts and is currently circulating in the market in the form of inventory spare parts. It is a discontinued or gradually replaced product.
